neodymium magnet for sale

 neodymium magnet for sale mainly comprised of neodymium ,iron and boron,is the third generation of the rare-earth permanent magnets,Sintered Ndfeb is the strongest permanent magnets in the world up to date,It has excellent properties of high remanence,coercivity,and Max.energy product.

neodymium magnet for sale

 Disc:Max:diameter 202mm*45mm thickness---Min:diameter 1.5mm*0.5mm thickness

Ring:Max:Od202mm*Id182mm*thickness 45mm---Min:Od 3mm*Id1mm*3mm thickness

Block:Max:L200mm*W200mm*T45mm---Min:L0.5mm*W0.5mm*T0.5mm

segment and other irregular shapes can be manufacture according to customer's sample or drawing.

neodymium magnet for sale grade

N35, N38, N40, N42, N45, N48, N50, N52(Max. Operational temperature: 80c)

N35M, N38M, N40M, N42M, N45M, N48M(Max. Operational temperature: 100c)

N35H, N38H, N40H, N42H, N45H, N48H, (Max. Operational temperature: 120C)

N33SH, N35SH, N38SH, N40SH, N42SH(Max. Operational temperature: 150c)

N28UH, N30UH, N33UH, N35UH, N38UH(Max. Operational temperature: Up to 180c)

N28EH, N30EH, N33EH, N35EH(Max. Operational temperature: Up to 200c)

N30AH, N33AH, N35AH(Max. Operational temperature: Up to 230c)

neodymium magnet for sale Outsanding product:

1)high performance:N52,N48M,48SH,42UH,38EH,33AH

2)high working temperature:the AH series with 40 k Oe super-high coervice force can replace SmCo magnets successfully.

3)high consistency:the cpk of Br and Hcj are much higher than 1.67 the consisitency of surface magnetic field and magnetic flux can be controlled with +/-1%

4)High Anti-corrosion:the sale spray test and humid heat test of the high anti-corrosion coating could be more than 1000 hours

5) low weight loss

PCT:130c ,humidity 100%,vapor pressure 2.7 bar.20 days,average low weight loss less than 2 mg/cm2

neodymium magnet for sale applications:

loudspeakers,motor assemblies,windmill,Home appliance,acousics,communication equipment,toy,car,servomotor,step motor,DC motor and linear motor,mircrophones

Pros: Very strong hold when contacting another magnet or plain iron, very difficult to pull away (easy to slide however).
Pretty strong hold between two of these even with a couple of mm in between.

Cons: Would like thicker (and more powerful) versions. Sure u can stack these together but sometimes it's not the same thing.

Other Thoughts: Good for attaching thick stacks of paper to refrigerators etc or pinching together papers or textiles.

Bottomline: This is the one if you need strong cost-effective magnets

Our factory:

you are welcome to enquiry on neodymium magnet for sale
