D3C cutting edge cutting blade for dozer blade 4T6232
- 2000 Piece / Pieces per Month
- shanghai
- T/T
- Internal gear 40cr 41A0076 for Liugong loader parts ,axle parts
- Liugong Wheel loader parts Liugong spare parts SP104817 Gland
- Liugong Spare parts Castle nut 03B0050 Standard parts for Liugong Wheel loader parts
- Conical roller bearing 23B0019 Standard parts for Liugong Wheel loader parts
- Liugong spare parts flasher relay 31B0005 fpr Liugong Wheel loader parts
- Air tank assembly ,pressure controller 13C0015 for Liugong Wheel loader parts
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | KTS | Model Number: | D3C |
Product Description
D3C cutting edge cutting blade for dozer blade 4T6232
1. OEM part number 7T9125, 6Y5540, 4T6381, 7T5702, 4T6659, 4T2988, 4T3010, 9W1878, 175-70-26310, 195-71-11654, 144-70-11131, 154-81-11191, 144-920-1120, 17M-71-21550, 195-71-61550......
2.Material: 16Mn Manganese steel and 30MnB Boron steel both with heattreatment.
3. Hardness:HB320~360 or HB440~480.
5.Thickness from 13mm to 60mm.
6. Different type:Double bevel flat cutting edge || , Cutting Edges |>, Cutting Edges < > , DBF serrated cutting edge.
7. Available to all brand bulldozer domestic and overseas especially for Caterpillar and Komatsu.
Material | Manganese steel | Boron steel |
Hardness | HB320-360 | HB440-480 |
Tensile(Rm Mpa) | 1250Rm-N/mm2 | 1620Rm-N/mm2 |
Elongation (A %) | 9% | 7% |
Impact test(AKV Joule) | 25°C 14J | 25°C 24J |
Fit models | CAT, Kom, Hyundai, Hitachi, Daewoo. etc |
