Top Bracket Type Hydraulic Hammer for Excavator and Wheel Loader

Top Bracket Type Hydraulic Hammer for Excavator and Wheel Loader thumbnail-1
Top Bracket Type Hydraulic Hammer for Excavator and Wheel Loader photo-1
US$ 500 - 10,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
KTS
Model Number:
All Model
Contact Supplier Request Quote Chat Now
Nanjing Katesi International Trading Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name KTS
Model Number All Model



Specifications

1.Low noise level
2.Full-closed bracket product the main body from damage
3.Powerful hammer
4.Easy maintenance



The Hydraulic Breaker has three style: 1. Side Style  Hydraulic Breaker;

                                                                 2. Silence Style  Hydraulic Breaker;

                                                       3. Top Style  Hydraulic Breaker.



This is a technical parameters:

MODEL DIA OF TOOL(φ mm) WEIGHT OF TOOL(kg) OPERATING WEIGHT(kg) OPERATING FLUX(1/min) OPERATING PRESSURE(bar) IMPACT RATE(bpm) APPLICABLE EXCAVATOR(m³) APPLICABLE EXCAVATOR(ton)
KTS10 45 6 122 20-40 90-120 700-1200 0.03-0.1 1.2-3.0
KTS20 53 9 153 25-50 90-120 600-1200 0.06-0.2 2.5-4.5
KTS30 70 19 330 40-70 110-140 500-900 0.15-0.30 4-7
KTS40 75 24 458 50-90 120-150 400-800 0.2-0.35 6-9
KTS50 85 32 591 60-100 130-160 400-800 0.25-0.5 7-14
KTS60 100 57 880 80-110 150-170 350-700 0.4-0.6 11-16
KTS70 120 89 1420 90-120 150-170 350-650 0.5-0.7 12-18
KTS75 125 98 1578 90-120 150-170 350-650 0.5-0.75 14-20
KTS80 135 131 1890 100-150 160-180 350-600 0.6-1.0 18-23
KTS90 140 142 2123 120-180 160-180 350-500 0.85-1.2 19-25
KTS100 140 140 2121 150-190 160-180 350-500 0.85-1.2 20-28
KTS130 150 164 2282 150-190 160-180 350-500 1.1-1.5 25-32
KTS150 155 183 2935 180-240 160-180 300-450 1.2-1.6 28-35
KTS160 155 197 3058 190-250 160-180 300-450 1.2-1.6 30-40
KTS190 160 200 3007 190-250 160-180 300-450 1.3-1.8 35-45
KTS200 175 263 3684 210-290 160-180 200-350 1.4-2.0 40-55





EXCAVATOR MODEL

MODEL KTS

1

DOOSAN DAEWOO

DH220 DH225 DH258

2

VOLVO

EC210 EC240

3

HITACHI

ZX200 ZX210 ZX220 ZX230

4

KATO

HD700 HD820 HD800 HD1023

5

KOBELCO

SK200 SK210 SK220 SK230 SK250

6

KOMATSU

PC200 PC210 PC220

7

SUMITOMO

S200 S260 S265

8

LIEBHEER

A912 A922

9

HYUNDAI

R200 R210 R220 R230

10

CAT

CT320 CT322 CT325

11

JONYANG

JY161 JY200

12

CHANGJIANG

WY120 WY203

13

LISHIDE

SC220.7

14

SANY HEAVY INDUSTRIES

SY200 SY210 SY220

15

LOADER





Top bracket type Hydraulic Hammer for Excavator and Wheel LoaderTop bracket type Hydraulic Hammer for Excavator and Wheel LoaderTop bracket type Hydraulic Hammer for Excavator and Wheel LoaderTop bracket type Hydraulic Hammer for Excavator and Wheel Loader

Our Main Products:

Top bracket type Hydraulic Hammer for Excavator and Wheel Loader



Our most competitive products: We can manufacture and design the excavator undercarriage according to customer's drawing and requirement.



Contact:



Maria





T:   86-25-83214972
F:   86-25-86598427



W:



Skype: mariaxu8



Don't hesitate to contact with us!
