Thrust Ball Bearing 51104 51105 Fitness Equipment Bearings

Jinan Yuki Bearing Co., Ltd.
Thrust Ball Bearing 51104 51105 Fitness Equipment Bearings thumbnail-1
Thrust Ball Bearing 51104 51105 Fitness Equipment Bearings photo-1
US$ 0.7 - 77.7 MOQ: 7 Pieces
Key Specifications
Get Latest Price
Brand Name:
YWS or OEM
Bore Size:
0.90, 100.00
Outside Diameter:
1.90, 101.00
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name YWS or OEM
Bore Size 0.90, 100.00
Outside Diameter 1.90, 101.00
Model Number 51104 51105
Precision Rating ABEC-1(P0),ABEC-3(P6),ABEC-5(P5),ABEC-7(P4),C3 V3
Seals Type open
Number of Row Single Row
Place of Origin Shandong, China

Specifications

thrust ball bearing fitness equipment bearing
1.Certification:ISO9001:2008:BV
2.Quality assurance
3.Good Service
4.OEM



Thrust ball bearing 51104 51105 fitness equipment bearings




Thrust ball bearing 51104 51105 fitness equipment bearings

 Thrust ball bearing 51104 51105 fitness equipment bearings

Thrust ball bearing 51104 51105 fitness equipment bearings



Thrust Ball Bearing

NO.1 Thrust ball bearing Type :


   According to the stress concentration points one-way thrust ball bearings and two-way thrust ball bearings. One-way thrust ball bearings, can withstand a one-way axial load. Bidirectional thrust ball bearing, it can be subject to bi-directional load.

   Bidirectional thrust ball bearing, which cooperate with shaft. Angled seat installation of spherical bearing, has the self-aligning properties, can reduce the influence of the installation error. Thrust ball bearing can't bear radial load, limit rotational speed is low.



NO.2 Thrust ball bearing Characteristics :



1. Thrust ball bearing Equipped with one-way, two-way two types



2. In order to allow installation error, either one-way or two-way, can choose spherical self-aligning spherical seat cushion    type or with spherical seat type.



3. High quality steel - used can extend bearing life highest 80% super clean steel



4. The height of the grease technology - lubricants technology can make the life of the grease to extend and improve the performance of the bearing



5. The high grade ball - quiet and smooth when high-speed rotation



6. Use of options in the ring, can allow installation error.



NO.3 Thrust ball bearing Application :



      Thrust ball bearing applies only to bear a part of the axial load and low speed, such as crane hook, vertical pumps, vertical centrifuge, jack, low speed reducer, etc. The shaft of the bearing ring, seat ring and rolling body is separate, can be installed separately.



Thrust ball bearing 51104 51105 fitness equipment bearingsThrust ball bearing 51104 51105 fitness equipment bearings

Thrust ball bearing 51104 51105 fitness equipment bearings

Thrust ball bearing 51104 51105 fitness equipment bearings

Thrust ball bearing 51104 51105 fitness equipment bearings





Ceramic Thrust Ball Bearing

Zirconia ceramics inside and outside the ring, PTFE cage, zirconia ceramic ball.
Product features:
1, due to the ceramic almost afraid of corrosion, so the ceramic rolling bearing is suitable for the corrosive fluids in harsh conditions.


2, due to the density of ceramic rolling ball is lower than steel, more much lighter weight, so the external ring spinning the centrifugal effect can reduce 40%, thus greatly extend the service life.


3, ceramics affected by heat bilges cold shrink is smaller than steel, thus in bearing clearance, allowing bearing in more severe working environment temperature change.


4, due to the elastic modulus of the ceramic is higher than steel, when the stress is not easy to deformation, thus to improve work speed, and achieve higher extract
Degrees.


Product use:
Plating equipment, cleaning machinery, medical equipment, cryogenic engineering, optical instrument, high-speed machine, high-speed electric machinery, printing machinery, food processing machinery.



Thrust ball bearing 51104 51105 fitness equipment bearingsThrust ball bearing 51104 51105 fitness equipment bearingsThrust ball bearing 51104 51105 fitness equipment bearings



We Can Desion and Produce Various Kinds of Bearing
1.Taper roller bearing2.Spherical roller bearing
3.Deep groove ball bearing4.Angular contact ball bearing
5.Thrust ball bearing6.Cylindrical roller bearing
7. Clutch bearing8. Needle bearing
9. Slewing bearing10. Wheel bearing
11. Aligning ball bearing12. Eccentric bearing
13. Non-standard bearing







Our Office Have the Second Test Quality Control Procedure

Thrust ball bearing 51104 51105 fitness equipment bearings



Package

Thrust ball bearing 51104 51105 fitness equipment bearings



About us

     Jinan Yuki Bearing Co., Ltd. is a Sino-Japanse joint ventured company, specializing in designing and manufacturing various types of bearings including deep groove ball bearings, spherical insert bearings, tapered roller bearings, angular contact ball bearings, thrust ball bearings, self-aligning roller/ball bearings as well as plastic bearings, ceramic bearing and so on. We could also provide OEM service according to our customers' requirements.
