29413 E Split Spherical Roller Bearing

29413 E Split Spherical Roller Bearing thumbnail-1
29413 E Split Spherical Roller Bearing photo-1
US$ 0.08 - 15 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Brand Name:
YWS or customer's brand
Bore Size:
20, 320
Outside Diameter:
52, 580
Contact Supplier Request Quote Chat Now
Jinan Yuki Bearing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name YWS or customer's brand
Bore Size 20, 320
Outside Diameter 52, 580
Model Number 29413 E
Precision Rating PO/P6
Seals Type open/zz/rs/2rs
Number of Row Double Row
Place of Origin Shandong, China

29413 E split spherical roller bearing

SPECIFICATION-- 29413 E spherical roller thrust bearings

29413 E split spherical roller bearing

bearing model number d D B C C0 Pu minimum load factor reference speed limiting speed mass
29413 E 65 140 45 455 1080 137 0,11 2600 4800 3,20
29414 E 70 150 48 520 1250 153 0,15 2400 4300 3,90
29415 E 75 160 51 600 1430 173 0,19 2400 4000 4,70
29416 E 80 170 54 670 1630 193 0,25 2200 3800 5,60
29317 E 85 150 39 380 1060 129 0,11 2400 4000 2,75
29417 E 85 180 58 735 1800 212 0,31 2000 3600 6,75
29318 E 90 155 39 400 1080 132 0,11 2400 4000 2,85
29418 E 90 190 60 815 2000 232 0,38 1900 3400 7,75
29320 E 100 170 42 465 1290 156 0,16 2200 3600 3,65
29420 E 100 210 67 980 2500 275 0,59 1700 3000 10,5
29322 E 110 190 48 610 1730 204 0,28 1900 3200 5,30
29422 E 110 230 73 1180 3000 325 0,86 1600 2800 13,5
29324 E 120 210 54 765 2120 245 0,43 1700 2800 7,35
29424 E 120 250 78 1370 3450 375 1,1 1500 2600 17,5
29326 E 130 225 58 865 2500 280 0,59 1600 2600 9,00
29426 E 130 270 85 1560 4050 430 1,6 1300 2400 22,0
29328 E 140 240 60 980 2850 315 0,77 1500 2600 10,5
29428 E 140 280 85 1630 4300 455 1,8 1300 2400 23,0
29230 E 150 215 39 408 1600 180 0,24 1800 2800 4,30
29330 E 150 250 60 1000 2850 315 0,77 1500 2400 11,0
29430 E 150 300 90 1860 5100 520 2,5 1200 2200 28,0
29332 E 160 270 67 1180 3450 375 1,1 1300 2200 14,5
29432 E 160 320 95 2080 5600 570 3 1100 2000 33,5
29334 E 170 280 67 1200 3550 365 1,2 1300 2200 15,0
29434 E 170 340 103 2360 6550 640 4,1 1100 1900 44,5
29236 E 180 250 42 495 2040 212 0,40 1600 2600 5,80
29336 E 180 300 73 1430 4300 440 1,8 1200 2000 19,5
29436 E 180 360 109 2600 7350 710 5,1 1000 1800 52,5
29338 E 190 320 78 1630 4750 490 2,1 1100 1900 23,5
29438 E 190 380 115 2850 8000 765 6,1 950 1700 60,5
29240 E 200 280 48 656 2650 285 0,67 1400 2200 9,30
29340 E 200 340 85 1860 5500 550 2,9 1000 1700 29,5
29440 E 200 400 122 3200 9000 850 7,7 850 1600 72,0
29244 E 220 300 48 690 3000 310 0,86 1300 2200 10,0
MAIN INFORMATION of 29413 E spherical roller thrust bearings
spherical roller thrust bearings are designed to achieve a high thrust capacity with low friction and continuous roller alignment. This bearing type is ideal for operating conditions that experience heavy loads, difficulty in establishing or maintaining housing alignment, or shaft deflection.
FEATURES AND BENEFITS-- 29413 E spherical roller thrust bearings
  • Spherically contoured rollers, arranged in a steep angular position, accommodate high thrust loads and support moderate radial loads.
  • Bearing geometry and manufacturing technology result in low friction of bearing.
  • Internal self-alignment of bearing elements during operation compensates for shaft deflections and housing distortions caused by shock or heavy loads.
  • The  inherent compensation for misalignment offers equipment designers the opportunity to use weldments for housing frames instead of complex castings, which reduces machining costs. When castings are preferred, bore alignment is less critical if spherical thrust bearings are specified.
  • “E” styles utilize enhanced bearing geometry allowing for higher dynamic load ratings and improved lubrication characteristics.
Other bearing we produce-- 29413 E spherical roller thrust bearings

29413 E split spherical roller bearing29413 E split spherical roller bearing

APPLICATION -- 29413 E spherical roller thrust bearings
  • Blowout preventers
  • Classifiers
  • Extruders
  • Gearboxes
  • Metal mill work/back-up rolls
  • Pre-heater fans
  • Pumps
  • Screw conveyors

29413 E split spherical roller bearing
