Home > Industrial Equipment & Components > Bearing > Pillow Block Bearing > SN Split Plummer Block Bearing Housing Units SN520 SN522 SN524 SN526

SN Split Plummer Block Bearing Housing Units SN520 SN522 SN524 SN526

SN Split Plummer Block Bearing Housing Units SN520 SN522 SN524 SN526 thumbnail-1
SN Split Plummer Block Bearing Housing Units SN520 SN522 SN524 SN526 thumbnail-2
SN Split Plummer Block Bearing Housing Units SN520 SN522 SN524 SN526 thumbnail-3
SN Split Plummer Block Bearing Housing Units SN520 SN522 SN524 SN526 thumbnail-4
SN Split Plummer Block Bearing Housing Units SN520 SN522 SN524 SN526 thumbnail-5
SN Split Plummer Block Bearing Housing Units SN520 SN522 SN524 SN526 thumbnail-6
SN Split Plummer Block Bearing Housing Units SN520 SN522 SN524 SN526 photo-1
SN Split Plummer Block Bearing Housing Units SN520 SN522 SN524 SN526 photo-2
SN Split Plummer Block Bearing Housing Units SN520 SN522 SN524 SN526 photo-3
SN Split Plummer Block Bearing Housing Units SN520 SN522 SN524 SN526 photo-4
SN Split Plummer Block Bearing Housing Units SN520 SN522 SN524 SN526 photo-5
SN Split Plummer Block Bearing Housing Units SN520 SN522 SN524 SN526 photo-6
US$ 10 - 30 MOQ: 1 Set
Key Specifications
Get Latest Price
Bore Size:
12, 100
Brand Name:
YWS
Model Number:
SN520 SN522 SN524 SN526
Contact Supplier Request Quote Chat Now
Jinan Yuki Bearing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Bore Size 12, 100
Brand Name YWS
Model Number SN520 SN522 SN524 SN526
Place of Origin Shandong, China

SN Split Plummer Block Bearing Housing Units SN520 SN522 SN524 SN526

SN Split Plummer Block Bearing Housing Units SN520 SN522 SN524 SN526



Product Description



                                                     Which quality is OK for you?



Japan Brand bearings housing



SN Split Plummer Block Bearing Housing Units SN520 SN522 SN524 SN526SN Split Plummer Block Bearing Housing Units SN520 SN522 SN524 SN526

SN Split Plummer Block Bearing Housing Units SN520 SN522 SN524 SN526SN Split Plummer Block Bearing Housing Units SN520 SN522 SN524 SN526SN Split Plummer Block Bearing Housing Units SN520 SN522 SN524 SN526



Bearings housing made in China

SN Split Plummer Block Bearing Housing Units SN520 SN522 SN524 SN526SN Split Plummer Block Bearing Housing Units SN520 SN522 SN524 SN526



 If you are interested in the following products, please click the below pictures!





self-aligning Spherical Roller Bearings

SN Split Plummer Block Bearing Housing Units SN520 SN522 SN524 SN526



self-aligning ball bearing

SN Split Plummer Block Bearing Housing Units SN520 SN522 SN524 SN526



Adapter sleeves

SN Split Plummer Block Bearing Housing Units SN520 SN522 SN524 SN526



Product Uses



MAIN INFORMATION

To ensure effective sealing, pillow (plummer) blocks are available with a variety of special seal options and end covers. Benefits include a facility for easy mounting and dismounting of pre-assembled shafts.

Pillow block housings can be used with high-capacity spherical roller bearings or self-aligning ball bearings. They are manufactured from high-strength cast iron as standard but are also available in cast steel or spheroidal graphite cast iron. The housings have a re-lubrication facility and can be used with either oil or grease lubrication.
FEATURES AND BENEFITS
  • High-grade bolts
  • Square-shape base – Facilitates alignment
  • High-precision bore – Maximizes bearing performance
  • Seal groove for various types of seals
  • Ideal casting design – High strength, rigid, and lightweight
  • Threaded hole for grease nipple – Plug for threaded hole is standard
  • Ideally shaped stiffer design
  • Large oil bath – Prolongs oil change interval
  • Webs for heat transfer
  • Rib for bearing seat – Prevents deformation of bearing seat
  • Ribs to minimize deformation caused by tightening the mounting bolts
  • Solid corners for locating pins
  • Center marks – Facilitates alignmen

SN Split Plummer Block Bearing Housing Units SN520 SN522 SN524 SN526

Packaging & Shipping





SN Split Plummer Block Bearing Housing Units SN520 SN522 SN524 SN526SN Split Plummer Block Bearing Housing Units SN520 SN522 SN524 SN526







Products Catalogue





Which sizes is OK for you?

SN Split Plummer Block Bearing Housing Units SN520 SN522 SN524 SN526





Related Products



ASSESSORIES

Adapter sleeves, locknuts, locking washers, withdrawal sleeves

Locating rings









Housing Shaft Dia     Bearing  Adapter Sleeve Locating Ring
No. d1   No.
    Wt
  mm in                                       (kg)   Number QTY


SN505 20 3/4                                       1.4 1205K 22205K H205 HE205 SR52x5 2
2205K H305 HE305 SR52x7 1
SN506 25 1                                       2.15 1206K 22206K H206 HE206 SR62x7 2
2206K H306 HE306 SR62x10 1
SN507 30 1-1/8                                       2.35 1207K 22207K H207 HE207 SR72x8 2
2207K H307 HE307 SR72x10 1
SN508 35 1-1/4                                       3.2 1208K 22208K H208 HE208 SR80x7.5 2
2208K H308 HE308 SR80x10 1
SN509 40 1-1/2                                       3 1209K 22209K H209 HE209 SR85x6 2
SSN509 4.4 2209K H309 HE309 SR85x8 1
SN510 45 1-3/4                                       3.75 1210K 22210K H210 HE210 SR90x6.5 2
SSN510 5 2210K H310 HE310 SR90x10 1
SN511 50 2                                       5.3 1211K 22211K H211 HE211 SR100x6 2
SSN511 7.15 2211K H311 HE311 SR100x8 1
SN512 55 2-1/8                                       6.3 1212K 22212K H212 HE212 SR110x8 2
SSN512 7.95 2212K H312 HE312 SR110x10 1
SN513 60 2-1/4                                       6.8 1213K 22213K H213 HE213 SR120x10 2
SSN513 9.9 2213K H313 HE313 SR120x12 1
SN515 65 2-1/2                                       7.4 1215K 22215K H215 HE215 SR130x8 2
SSN516 9.3 2215K H315 HE315 SR130x10 1
SN516 70 2-3/4                                       11.4 1216K 22216K H216 HE216 SR140x8.5 2
SSN516 14.5 2216K H316 HE316 SR140x10 1
SN517 75 3                                       11.1 1217K 22217K H217 HE217 SR150x9 2
SSN517 15.5 2217K H317 HE317 SR150x10 1
SN518 80 3-1/4                                       17 1218K 22218K H218 HE218 SR160x16.2 2
SSN518 20.2 2218K 23218K H318 HE318 SR160x11.2 2
        H2318 HE2318 SR160x10 1
SN519 85                                         15.5 1219K 22219K H219 HE219 SR170x10.5 2
SSN519 2219K H319 HE319 SR170x10 1
SN520 90 3-1/2                                         2220K 22220K H320 HE320 SR180x12.1 2
SSN520 27.5 23220K H2320 HE2320 SR180x10 1
SN522 100 4                                       29 2222K 22222K H322 HE322 SR200x13.5 2
SSN522 35 23222K H2322 HE2322 SR200x10 1
SN524 110 4-1/4                                       33.6   22224K H3124 HE3124 SR215x14 2
SSN524 43.8 23224K H2324 HE2324 SR215x10 1
SN526 115 4-1/2                                       41   22226K H3126 HE3126 SR230x13 2
SSN526 50.4 23226K H2326 HE2326 SR230x10 1
SN528 125 5                                       49   22228K H3128 HE3128 SR250x15 2
SSN528 62 23228K H2328 HE2328 SR250x10 1
SN530 135                                         60   22230K H3130 HE3130 SR270x16.5 2
SSN530 75 23230K H2330 HE2330 SR270x10 1
SN532 140 5-1/2                                       68.8   22232K H3132 HE3132 SR290x17 2
SSN532 87 23232K H2332 HE2332 SR290x10 1
