Specifications
feed gearbox Bearings:d turbine slewing bearing
2.GB/T2300-1999 standard
3.High quality & competitive price
feed gearbox Bearings :
NO.1. Slewing Bearings application
Slewing bearing is widely applied in current industry, known as: "machine joints", its main applications are widely used in: automobile crane, rail cranes, port cranes, deck cranes, metallurgical cranes, container cranes, excavators, filling machine, and CT machine standing wave therapy apparatus, navigation instrument and radar antenna, missile launcher, tanks and robots, and a revolving restaurant, etc
NO.2. Slewing Bearings type
1. Single-row 4-point contact ball series.
2. Single-row crossed roller series.
3. Double-row ball series.
4. Three-row roller series.
5. Roller and ball combination series.
6. Light type profile slewing bearing.
7. Quenching slewing ring bearing
NO.3. Slewing Bearings about us:
Products name |
Bearing, Pillow block bearing , insert bearing
|
Brand name |
YWS or OEM Brands |
ID size |
Standard and non-standard sizes available |
Material |
Carbon Steel / Chrome Steel |
Closures |
Open, metal Sealed, rubber sealed, Nylon sealed |
Types |
For non standard bearing,there are many different types with various sizes for our clients and we can alsodesign or develop customized products as per the samples or drawings provided by our clients. |
Delivery date |
2-25 days |
Payment terms |
A: 30% T/T in advance .70% against copy of B/L B.30% T/T in advance .70% against L/C at sight C.Western union D.Paypal |
About us |
Established in 2004, Jinan yuki bearing Co., Ltd. is a sino-japanese joint ventured company and one of the leading bearing manufacturers in China. With 20 years’ experience, advanced manufacturing facilities and excellent management staff, we can produce products that are equivalent to the world leading brand bearings. We have our own bearing brand YWS and also distribute bearings of global brands, |
Package |
A.Polybag +Box+Carton B.Tube+Box+Carton C.As per customer's request |
|
|
NO.4. Slewing Bearings about BEARING:
Part |
Material |
feature |
|
Rolling element |
Gcr15/Gcr15SiMn |
whole quench hardening |
|
Rings |
50Mn/42Mocr/S48S |
Surface quench hardening |
|
Retainer |
ZL102 cast aluminium alloy/polyamide110 resin/Nylon GRPA66.25/stainless steel NO20 |
abrasion resistance |
|
sealing ring |
NBR rubber |
oil resistance |
|
All above could produce according to customer's requirement |
|
||
NO.5. Slewing Bearings about SOME MODEL:
model |
d |
D |
T |
Weigth |
model |
d |
D |
T |
Weigth |
(mm) |
(mm) |
(kg) |
(mm) |
(mm) |
(kg) |
||||
F-QW1250.40 |
1084 |
1476 |
110 |
483 |
797/1320G2 |
1320 |
1715 |
134 |
958 |
D8788/830 |
830 |
1040 |
101 |
148 |
797/1278G2K |
1250 |
1700 |
155 |
1103 |
D5792/900 |
900 |
1150 |
90 |
227 |
797/1200G2 |
1200 |
1520 |
90 |
504 |
798/525 |
525 |
725 |
80 |
98 |
797/1200 |
1200 |
1520 |
105 |
575 |
797/962G2 |
962 |
1200 |
90 |
224 |
797/1060G2 |
1060 |
1400 |
120 |
596 |
797/870K |
870 |
1180 |
115 |
355 |
792/710 |
710 |
940 |
90 |
52 |
797/845G2 |
845 |
1150 |
130 |
393 |
792/2800G |
2800 |
3310 |
190 |
2864 |
797/700G |
700 |
1000 |
140 |
370 |
792/1250G2 |
1250 |
1700 |
155 |
1103 |
797/670 |
670 |
907 |
85 |
170 |
792/1000G2K |
1000 |
1270 |
100 |
303 |
797/2500G2 |
2500 |
2980 |
180 |
2913 |
792/1000G2 |
1000 |
1270 |
100 |
303 |
Bearing, feed gearbox Bearings
