Technical Specification
| Model | jiangdong engine parts |
| cylinder bore (mm) | 115 |
| piston stroke (mm) | 115 |
| rated output (kw) | 14.7 |
| rated speed r/min | 2200 |
| overall dimension (mm) | 858*450*699 |
| net weight(kg) | 185 |
Other Models
| MODEL | TECHNICAL SPECIFICATION | |||||
| Cylinder Bore (mm) | Pision Stroke (mm) | Rated Output (kw) | Rated Speed (r/min) | Overall dimension(L×W×H)(mm) | Net weight (kg) | |
| R165 | 65 | 60 | 2.12 | 2600 | 473*280*351 | 29 |
| R170A | 70 | 60 | 2.72 | 2600 | 473*280*351 | 31 |
| R175A | 75 | 80 | 4.55 | 2600 | 589*341*463 | 60 |
| R176 | 76 | 65 | 3.82 | 3000 | 498*294*360 | 35 |
| R180 | 80 | 80 | 5.15 | 2600 | 625*341*460 | 72 |
| R190 | 90 | 90 | 7 | 2300 | 700*390*570 | 100 |
| ZR192 | 92 | 90 | 7.7 | 2400 | 700*390*570 | 100 |
| ZS195 | 95 | 115 | 8.82 | 2200 | 770*480*620 | 145 |
| ZS1100 | 100 | 115 | 11.03 | 2200 | 770*480*620 | 150 |
| ZS1105 | 105 | 105 | 12.13 | 2200 | 770*480*620 | 160 |
| ZS1110 | 110 | 115 | 13.24 | 2200 | 358*450*699 | 180 |
| ZS1115 | 115 | 115 | 14.7 | 2200 | 858*450*699 | 185 |
| ZS1115A (TD24) | 115 | 120 | 16.7 | 2200 | 858*450*699 | 185 |
| ZS1125A (TD26) | 125 | 120 | 18.38 | 2200 | 930*480*699 | 190 |
| ZS1130 (TD30) | 130 | 120 | 21.3 | 2200 | 930*480*699 | 205 |
ZS1115
Warranty that is valid globally, everywhere Starblaze-authorized service is available.Starblaze marine engine are supported in every major port by a global team of marine-certified distributors offering sales, service and application expertise.
1. How to get an accurate quotation?
To get a quotation list, please send inquiry on Alibaba or send email to us directly. The email addresses are shown in the contact detail page.
As we have different models, please indicate following details in your inquiry email,
a) Output (how many HP) or Model No.
b) Cooling system (evapoative / radiator)
c) Starting method (hand crank / motor start)
d) Order quantity!
These are very important for providing you an accurate and favorable price.
2. What is the minimum order quantity?
Our minimum order quantity is 5 sets in an order.
3. About the shipment
Usually if you didn't indicate the shipping requirement in the inquiry email, we will quote on FOB price which does't include shipping cost.
4. Usage
Starblaze offers a complete line of propulsion, engine and auxiliary power solutions designed specifically for the challenges of commercial marine applications
5.Advantage
(1Small seize,light weight ,low fuel consumption,long service time,easy starting and convenientmaintenance ect.
(2Wide application:engineering machineries, mining machineries,automobiles, agriculural equipments generating equipments, medium and small ship ect.
(3Fine adaptablity:reliable in dry,hot cold weather and in poor water quality condition as well as in highland area and low pollution requested working environment
We will give you the competitive price
