Single Needle Automatic Quilting Machine For Quilt And Mattress
- Qingdao
- T/T Money Gram
You May Like
-
Single Needle Computerized Quilting Sewing Embroidery Machine
-
Automatic Single Needle High Speed Mattress Quilting Machine
-
Single Needle Single Head Computer Quilting Machine
-
QY Series Single Needle Quilting Machine Exported to Bolivia
-
Flexible QY-26 Computerized Single Head Quilting Machine
-
Exported to Bolivia Good Quality Single Head Quilting Machine
Product Details
| Condition | New | Place of Origin | Shandong, China | |
| Brand Name | Qinyuan | Model Number | Qy-26 | |
| Max Sewing Speed | 2200 needle/points | Max Sewing Thickness | 1500 g/square | |
| Number of Head | Single Head | Moving Style | Head Moved | |
| Voltage | 220V | Power(W) | 1.5KW | |
| Dimension(L*W*H) | 3800*5000*1670mm | Weight | 2.2 Ton | |
| Certification | CE | Warranty | 1 Year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Single Needle Automatic Quilting Machine For Quilt And Mattress
Specification |
1) with 12 "LCD monitor, g-kong mainframe computers. A Chinese and English two operating version. Using synchronous belt transmission, quilting high precision, low noise. Sewing suture mark: single head two-lane locks type. The computers more than existing 500 quilting pattern. |
2) voltage power: 220V, 50HZ, 1.5 KW |
3) have disconnection stop function. |
4) safety device: computers, motor, so unusual phenomenon machine will automatically stop working, and pictures showed fault content. |
5) figure adopts DST and DAT dozen edition system |
6) match USB interface |
7) stitch 6mm adjusting range: 2-7mm |
8) needle type: DP5 18 ~ 22 # |
9) maximum quilting speed: 2200 needle/points |
10) maximum sewing thickness: 1500 g/square |
Specifications | QY-26 W*L*H/m
| QY-28 W*L*H/m | QY-30 W*L*H/m
| QY-32 W*L*H/m |
Max Quilt Size | 2.6x 2.8 | 2.8x 3.2 | 3.0 x 3.2 | 3.2 x 3.5 |
Max Needle Drop Size | 2.4x 2.6 | 2.6x 3.0 | 2.8 x 3.0 | 3.0x 3.3 |
Machine size | 5.2x 4.0 x 1.6 | 5.6 x 4.2 x 1.6 | 5.6x 4. 4x 1.6 | 5.9x4.6 x 1.6 |
Packaging size
| 4.2x 0.92 x 2.0 | 4.4x 0.92 x 2.0 | 4.6x 0.92 x 2.0 | 4.8x0.92 x2.0 |
Gross weight | 2200kg | 2400kg | 2600kg | 2800kg |
Net weight | 2000kg | 2200kg | 2400kg | 2600kg |
Feature: |
1)The main shaft speed has been raised and work efficiency has been increased. |
2)Application of large rotation shuttle while the shuttle core is two times larger than that of small shuttle. |
3)The system has testing function so as to have convenient maintenance. |
4)Patterns has the function of rotation and overturn. |
1) We are a professional machine factory for over 20 years;
2)Our company dealing with many kinds of quilting machine,bobbin winder machine,mattress tape edge machine, cutting machine,Quilting Embroidery Machine etc.
3)Our engineers are continous studying advanced technology from developed country, in order to make our machines better suit the customers' needs.
Q:What kind of work does your company do?
A:Our company is a professional manufacturer.We mainly dealing with many kinds of quilting machine,bobbin winder machine,mattress tape edge machine, cutting machine,quilting embroidery machine etc.
accordance with customers' requirement.
Q:What are the advantages of your company?
A: We have many professional technical personnel.And we have more competitive prices,high quality and better service than trading companies.
Q:How do you control the quality?
A:Our company is CE certificated .We have many inspectors and every product will have been tested for 4-5 processes.We welcome customers visit to our factory.
Q:What about your price?
A:Our price is very competitive because we are a factory.Please contact us if you are interested in our products.
Q:How long is your delivery time?
A:Different products have different delivery time.The products will be delivered as soon as possible on the basis of the quality assurance.Usually the delivery time is within 10-15 days after we recieved your deposit.
Q: Do you have CE certificate for all your machines?
A:Yes,we have CE certificate.If you need, please contact us for details.
