Help CenterClutch (Shear Bolt Torque Limiter) for Pto Shaft Used in Farm Machines
Related Products
-
1 3/8" Z6 Quick Release Yoke of PTO Shafts for Agricultural TractorsNegotiableMOQ: 100 Sets -
End Yoke of PTO Shafts for Agricultural TractorsNegotiableMOQ: 100 Sets
-
Yokes for PTO ShaftNegotiableMOQ: 50 Sets
-
Quick Release PTO Shaft Yoke for Agricultural TractorsNegotiableMOQ: 100 Sets
-
Quick Release Yoke for PTO Shaft / Driveline/ Cardan ShaftNegotiableMOQ: 100 Sets
Specifications
We have CLUTCH such as friction torque limiter, ratchet torque limiter, shear bolt torque limiter for PTO Shaft/
Our factory is specialized in producing PTO SHAFT for farm machine. We supplied spare parts to Euro Cardan in Italy and for other companies all over the world.Agricultural PTO shaft Features:
1. We provide pto shaft series 1#, 2#, 3#, 4#, 5#, 6#, 7#, 7N#, 8#.
2.Cross journal specifications:
series1#: 22 * 54mm
series 2#: 23.8 * 61.3mm
series 3#: 27 * 70mm
series 4#: 27 *74.6mm
series 5#: 30.2 * 80mm
series 6#:30.2 * 92mm
series 7#: 30.25*106.35mm
series 7N: 35*94mm
series 8: 35 * 106.5mm
3.Types of tube: triangle profile tube, lemon profile tube.
4. Minimum overall length: 600-1800mm or 27"-60"
5.End yokes & safety devices: quick release yokes, plain bore yokes, friction type torque limiters, ratchet type torque limiter, shear bolt torque limiter, etc.
6.Plastic safety guard: black or yellow.
We also provide splined shaft.If you have any interest, please don't hesitate to let us know. You could visit our website for more detailed information.
Iron pallet packing. Weight and measure is in accordance with different series and overall length of each PTO SHAFT
