Specifications
High quality pto shaft tube ytoke
1. All parts are forged.
2. Sample welcome
3. LOW MOQ
Application :
1. For Tractor, Rotary Cultivator, Planter Machine, Farm and etc.
2. Wide Angle Joint, Shear Bolt Torque Limiter, Friction Torque Limiter.
3. Cross Journal Size: Series 1# to Series 8#
4. CE Certificate.
tube yoke for pto shaft Technical data:
| 540rpm | 1000rpm | ||||||||||
| SERIES | FIDEL REF. | CROSS | INNER | OUTER | Kw | Hp | Nm | Kw | Hp | Nm | SPLINE |
| 1 | T1 | 22x54 | 26x3.5 | 32.5x2.6 | 12 | 15 | 210 | 18 | 23 | 170 | 1 3/8" Z-6 |
| 2 | T2 | 23.8x61.3 | 29x4 | 36x3.2 | 16 | 21 | 280 | 24 | 33 | 230 | 1 3/8" Z-21 1 3/4" Z-6 |
| 3 | T3 | 27x70 | 36x4.4 | 43.4x3.3 | 21 | 29 | 400 | 33 | 44 | 320 | 1 3/4" Z-20 |
| 4 | T4 | 27x74.5 | 36x4.4 | 43.4x3.3 | 27 | 36 | 460 | 40 | 55 | 360 | |
| 5 | T5 | 30.2x80 | 45x4 | 53.6x3.8 | 39 | 52 | 620 | 60 | 81 | 500 | |
| 6 | T6 | 30.2x92 | 45x4 | 53.6x3.8 | 48 | 64 | 850 | 73 | 100 | 690 | |
| 7 | T7 | 30.2x106.5 | 45x4 | 54x4 | 55 | 72 | 1000 | 78 | 115 | 810 | |
| 7N | T7N | 35x94 | 45x5.5 | 54x4 | 59 | 79 | 970 | 91 | 122 | 830 | |
| 8 | T8 | 35x106.5 | 54x4 | 63x4 | 75 | 100 | 1250 | 115 | 154 | 1020 | |
Tube: 2-lemon tube, 3-lemon tube ( triangular tube), square tube, involute tube, star tube.
Yoke: Forged or casting steel
Yoke type: quick release, auto lock, overuning clutch, slip clutch, etc.
Spline Shaft: Harded.
Supply PTO DRIVESHAFT assembly:
Varieties hole, pin fork, break tank, 6 tooth, 20 tooth, 21 tooth spline fork
Triangle shaped tube, lemon tube, pipe welding fork Star
High, medium and low block universal joint assembly
After high temperature heat treatment spring pins
Li pin, etc.
High-strength bolts, cap gong
Fast elastic plastic, metal sleeve spline fork
Constant velocity joints and other high-powered clutch
Sharp cut-type forks, forks and so fast elastic
Multi-tooth spline. Specifications from the 1 3 / 8 "Z6, 1 1 / 8" Z6, 1 3 / 4 "Z6, 1 3 / 8" Z20, 1 1 / 8 "Z20, 1 3 / 4" Z20, 1 3 / 8 "Z21 , 1 1 / 8 "Z21, 1 3 / 4" Z21, etc., complete specifications are welcome.
Why Speedway?
1. Customized and designed according to the customers' sample, drawing or requirements.
2. Following the customers' requirements or as our usual packing
3. Customer-First, Price-Competitive, Quality- High, Services- Professional.
4. Flexible minimum order quantity
For more information about us, contact us right away.
Q1: Can I buy one of your products for Sample?
A: Yes, we can provide you sample, and will send you by DHL or according to your requirements, or find the cheapest forwards for you.
Q2: How could I know if the product suitable for my machine or not?
A: Pls tell us which product you are interested in, We will give you the main sizes, or you can provide your drawings or samples, we will make according to your drawings.
Q3: I want to find a supplier for my new products, can you help me ?
A: Yes, kindly offer us your drawings or samples. We will quote you the cost.
Q4: How long for your to make a new products?
A: Usually 20-35days for the drawing ones and 35-60 days for the sampled ones.
Q5: What is the payment method?
A: Our payment method: T/T, WEST UNION, PAYPAL.
Q6: How is the quality?
A: Strict control before shipment.
Q7: What are our major market?
A: Our main markets are Middle east, Africa, Southeast Asia and South America, European…
