Home > Construction & Decoration > Wire Mesh > Stainless Steel Wire Mesh > Stainless Steel Woven Wire Mesh
Negotiable
MOQ: 5 Rolls (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
Tenglu
Place of Origin:
China
Material:
Stainless Steel Wire
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin
Delivery Detail:
20 days
Related Products
-
SUS304/316 Welded Wire MeshUS$ 95 - 350MOQ: 50 Rolls -
Stainless Steel Metal Woven Mesh for Interior DecorationNegotiableMOQ: 50 Square Meters
-
New Outdoor PVC Mesh Mesh PVC Mesh Fabric Textilene Woven Mesh Fabric Two-Color PVC Woven Mesh Fabric WholesaleUS$ 1.2 - 1.5MOQ: 1000 Square Meters
-
Hexagonal Woven Mesh Gabion Baskets 2m X 1m X 0.5mUS$ 1.99 - 2.50MOQ: 200 Square Meters
-
Virgin HDPE Woven Mesh Anti Insect Pest Net for Agricultural Farmer UseNegotiableMOQ: 1
Brand Name
Tenglu
Place of Origin
China
Material
Stainless Steel Wire
Type
Wire Cloth
Application
Woven Wire Mesh
Technique
Woven
Weave Style
Plain Weave
Stainless steel woven wire mesh offer flat surface, firm structure and good integrity. It is widely used in industry, agriculture, construction, breeding, transport, mining exploitation, transport, entertainment facilities and other public places.
Materials: Stainless steel woven wire meshes are generally made of stainless steel Type 302,304,304L,316,316L,321 and 430 etc. Many different grades of stainless are used in wire cloth.T304 is the most common one, but others are also used in specific applications
Weaving Types:Plain or Twilled Weave, Plain or Twilled Dutch Weave, Five heddle Weave, Reverse Plain or Twilled Dutch Weave
The weaving is determined according to our customers' specific requirements, such as the material, the wire diameter, the size of the mesh , width and length.
Stainless steel woven wire mesh is widly used in mining, petroleum, chemical industry, food industry , pharmaceutical industry and sifting and screening mesh in chemical and chemical fiber industry.
| Stainless Steel Wire Mesh Commen Specifications | ||||||
| Mesh/Inch | Wire Diameter | Aperture | Open Area | Weight(LB) /100 Square Foot | ||
| Inch | MM | Inch | MM | |||
| 1x1 | 0.08 | 2.03 | 0.92 | 23.37 | 84.6 | 41.1 |
| 2X2 | 0.063 | 1.6 | 0.437 | 11.1 | 76.4 | 51.2 |
| 3X3 | 0.054 | 1.37 | 0.279 | 7.09 | 70.1 | 56.7 |
| 4X4 | 0.063 | 1.6 | 0.187 | 4.75 | 56 | 104.8 |
| 4X4 | 0.047 | 1.19 | 0.203 | 5.16 | 65.9 | 57.6 |
| 5X5 | 0.041 | 1.04 | 0.159 | 4.04 | 63.2 | 54.9 |
| 6X6 | 0.035 | 0.89 | 0.132 | 3.35 | 62.7 | 48.1 |
| 8X8 | 0.028 | 0.71 | 0.097 | 2.46 | 60.2 | 41.1 |
| 10X10 | 0.025 | 0.64 | 0.075 | 1.91 | 56.3 | 41.2 |
| 10X10 | 0.02 | 0.51 | 0.08 | 2.03 | 64 | 26.1 |
| 12X12 | 0.023 | 0.584 | 0.06 | 1.52 | 51.8 | 42.2 |
| 12X12 | 0.02 | 0.508 | 0.063 | 1.6 | 57.2 | 31.6 |
| 14X14 | 0.023 | 0.584 | 0.048 | 1.22 | 45.2 | 49.8 |
| 14X14 | 0.02 | 0.508 | 0.051 | 1.3 | 51 | 37.2 |
| 16X16 | 0.018 | 0.457 | 0.0445 | 1.13 | 50.7 | 34.5 |
| 18X18 | 0.017 | 0.432 | 0.0386 | 0.98 | 48.3 | 34.8 |
| 20X20 | 0.02 | 0.508 | 0.03 | 0.76 | 36 | 55.2 |
| 20X20 | 0.016 | 0.406 | 0.034 | 0.86 | 46.2 | 34.4 |
| 24X24 | 0.014 | 0.356 | 0.0277 | 0.7 | 44.2 | 31.8 |
| 30X30 | 0.013 | 0.33 | 0.0203 | 0.52 | 37.1 | 34.8 |
| 30X30 | 0.012 | 0.305 | 0.0213 | 0.54 | 40.8 | 29.4 |
| 30X30 | 0.009 | 0.229 | 0.0243 | 0.62 | 53.1 | 16.1 |
| 35X35 | 0.011 | 0.279 | 0.0176 | 0.45 | 37.9 | 29 |
| 40X40 | 0.01 | 0.254 | 0.015 | 0.38 | 36 | 27.6 |
| 50X50 | 0.009 | 0.229 | 0.011 | 0.28 | 30.3 | 28.4 |
| 50X50 | 0.008 | 0.203 | 0.012 | 0.31 | 36 | 22.1 |
| 60X60 | 0.0075 | 0.191 | 0.0092 | 0.23 | 30.5 | 23.7 |
| 60X60 | 0.007 | 0.178 | 0.0097 | 0.25 | 33.9 | 20.4 |
| 70X70 | 0.0065 | 0.165 | 0.0078 | 0.2 | 29.8 | 20.8 |
| 80X80 | 0.0065 | 0.165 | 0.006 | 0.15 | 23 | 23.2 |
| 80X80 | 0.0055 | 0.14 | 0.007 | 0.18 | 31.4 | 16.9 |
| 90X90 | 0.005 | 0.127 | 0.0061 | 0.16 | 30.1 | 15.8 |
| 100X100 | 0.0045 | 0.114 | 0.0055 | 0.14 | 30.3 | 14.2 |
| 100X100 | 0.004 | 0.102 | 0.006 | 0.15 | 36 | 11 |
| 100X100 | 0.0035 | 0.089 | 0.0065 | 0.17 | 42.3 | 8.3 |
| 110X110 | 0.004 | 0.1016 | 0.0051 | 0.1295 | 30.7 | 12.4 |
| 120X120 | 0.0037 | 0.094 | 0.0064 | 0.1168 | 30.7 | 11.6 |
| 150X150 | 0.0026 | 0.066 | 0.0041 | 0.1041 | 37.4 | 7.1 |
| 160X160 | 0.0025 | 0.0635 | 0.0038 | 0.0965 | 36.4 | 5.94 |
| 180X180 | 0.0023 | 0.0584 | 0.0033 | 0.0838 | 34.7 | 6.7 |
| 200X200 | 0.0021 | 0.0533 | 0.0029 | 0.0737 | 33.6 | 6.2 |
| 250X250 | 0.0016 | 0.0406 | 0.0024 | 0.061 | 36 | 4.4 |
| 270X270 | 0.0016 | 0.0406 | 0.0021 | 0.0533 | 32.2 | 4.7 |
| 300X300 | 0.0051 | 0.0381 | 0.0018 | 0.0457 | 29.7 | 3.04 |
| 325X325 | 0.0014 | 0.0356 | 0.0017 | 0.0432 | 30 | 4.4 |
| 400X400 | 0.001 | 0.0254 | 0.0015 | 0.37 | 36 | 3.3 |
| 500X500 | 0.001 | 0.0254 | 0.001 | 0.0254 | 25 | 3.8 |
| 635X635 | 0.0008 | 0.0203 | 0.0008 | 0.0203 | 25 | 2.63 |
