Cross Roller Slewing Ring Bearing
US$ 180 - 180
/ Set
10 Sets(Min. Order)
- QINGDAO
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Turn Table Roller Bearings YRT260
-
Transmission Equipment Bearings H211 Adapter Sleeve Bearing
-
Spherical Roller Bearings 22000 Series Bearing on an Adapter Sleeve
-
Y-bearings YSA 205-2FK Bearing on an Adapter Sleeve HE2305
-
Bearing Accessories Adapter Sleeve H309 Bearing
-
Sleeve Bearings HE211 Adapter Sleeves Bearing
Product Details
| Brand Name | CLUNT | Bore Size | 395, | |
| Outside Diameter | 525, | Model Number | YRT395 | |
| Feature | Cross Roller | Gear Options | External Gear Only | |
| Seals Type | OPEN | Place of Origin | Shandong, China |
Product Description
Product Description
| Application area | |
. | Costruction Equipment ,Tunnel Boring Machines |
| . | Engineering Machine & Vehicles,Drilling machine sets |
| . | Excavators,Crane,Tower Crane |
| . | CT Medical Machine |
| . | Wind Power Generation System |
| . | Mining/shipping port/Light industry/petrochemical/entertainment Machiney |
| . | Millitary equipment |
| Main slewing ring bearing type | |
| . | Single-row four-point contact ball series. |
| . | Single-row crossed roller series. |
| . | Double-row ball series. |
| . | Three-row roller series. |
| Part | Material | feature |
| Rolling element | Gcr15/Gcr15SiMn | whole quench hardening |
| Rings | 50Mn/42Mocr/S48S | Surface quench hardening |
| Retainer | ZL102 cast aluminium alloy/polyamide110 resin/Nylon GRPA66.25/stainless steel NO20 | abrasion resistance |
| sealing ring | NBR rubber | oil resistance |
| All above could produce according to customer's requirement | ||
| Manufacture equipment | Test tool |
| Forging oil press | 5m Test balancer |
| Forging ring rolling machine | hardness tester |
| The reclaimer/Ingot | light wave flaw detector |
| Quenching and tempering furnace | tensile strength tester |
| Hob ginding machine/Travelling crane | hardness test press |
| Natural Gas forge furnace | physical chemistry snalyzer |
| Tempering furnace/Temper stove | 150mm-5000mm vernier caliper |
| intermediate frequency quenching equipment | sub micrometer diameter |
| Lather/NC Lathe/Vertical lathe/NC lineation | Universal angle rule |
| Rocker driller/Gear Shaper/NC drilling machine | Tooth thickness gauge |
| Hoobing machine/carbon sulfur analyzer | quenching concentration meter |
| Air Compressor | intelligent three element hight-speed analyzer |
| Plane grinding machine | carbon sulfur analyzer |
| grinding machine | Electric arc furnace |
| Packing | |
| First lubricated, Second circled with plastic film/kraft paper/blue belt,then pakaged in wooden case,last gethered in Wooden pallet. | |
| Others | |
| MOQ | 1piece |
| Lead time | 30 days |
| Payment terms | T/T/L/C/Escrow/Wester union/ |
5.Transportation
| Transportation | |
| GR have build a long term cooperation with Alibaba one touch which is specialized in importer and exporter operation. | |
| Our Service | |
| 1 | OEM service provided |
| 2 | Processing with supplied drawings |
| 3 | Providing replacement Kaydon/Komatsu/Hitachi/Volvo/Caterpillar/Kato/Sumitomo/Kobelco/Daewoo/Doosan/Hyundai/Case /JCB/liebherr/Kubota/Takeuchi/Hisce/Terex/Lovol slewing bearing ring etc. |
| 4 | Providing all the replacement slewing bearing ring. Zoomliom,sunward,sany......etc. |
| Remark:Could provide slewing bearing ring with different quality level as customer's requirement. | |
| Type size and kind |
| Type XRB (outer ring) |
| XRB series models (THK corresponding model for the RB series, IKO corresponding model for the CRB series) for cross circle |
| Cylindrical roller bearing, basic, inner and outer ring size is minimal to miniaturization, its structure is the outer ring is divided, the inner ring design is an organic whole, the inner ring spinning of high precision parts suitable for requirements. |
| Type XRE (inner ring) |
| XRE series model (THK corresponding model series for the RE series) is produced by the XRB type design concept of new type, main dimensions is the same as the XRB type.Its structure is the inner ring is split type, outer ring design is an organic whole, is suitable for outer ring rotation of high precision parts. |
| XRU type (inner and outer ring size) |
| XRU series models (corresponding to THK company RU series and IKO CRBF series) is due to the processing of mounting holes, there is no need for a fixed flange and brackets.In addition, due to the adoption of arrange ushering the integration of internal and external ring structure, the installation will have little impact on performance, thus can obtain the stable rotation accuracy and torque.Can be used for outer ring and inner ring spinning. |
| Type XRBC (outer ring) |
| Corresponding IKO company CRBC XRBC series models (series) of its structure is the outer ring is split type, design of the inner ring is an organic whole, with cage full roller bearings.Suitable for the inner ring rotation accuracy demanding position. |
| XRBH type (inner and outer ring size) |
| Corresponding IKO company CRBH XRBH series models (series) of internal and external ring structure is an organic whole, used for outer ring and inner ring spinning. |
| XRA type (outer ring segmentation, ultra-thin) |
| XRA series model series of corresponding THK company (RA) is the thickness of the inner and outer ring will XRB type compact decreased to the limit.Suitable for the need of light weight, compact design, such as robots and mechanical rotating parts. |
| Type XRC (outer ring) |
| XRC series models ( company SX series), the structure is similar to the XRB series, outer ring is two integral structure, through three spring snap ring connection, the inner ring body design, apply to the inner ring spinning demand of high precision. |
| XRSU08 type (inside and outside the circle shape) |
| XRSU08 series models ( company XSU08 series) similar to XRU series, inner and outer rings are for the processing of mounting holes, there is no need for a fixed flange and brackets.In addition, due to the adoption of arrange ushering the integration of internal and external ring structure, the installation will have little impact on performance, therefore to stability |
Product Picture
company information
My company equipment is advanced, leading the management level, the warehouse clean and orderly, mount guard after qualified staff skill training, greatly improve the quality of our products and reduce the production cost, follow up competitiveness in the bearing industry.Our company pays attention to technology innovation the technological innovation enables enterprises to form core competitiveness, and to keep a competitive strength.
1: Germany equipment,
2: dust-free workshop,
3: smokeless workshop,
4:5 s management system,
5: ERP warehouse outbound,
Welcome to visit our factory, and promote the communication and learning, and go further in the bearing industry .
Our company quality first gained international certification
International certification:
1: ISO9001:2000,
2: BV,
3: CC,
Inland certification:
1: Shandong star enterprise ,
2: Domestic well-known brand,
3: Five years gold supplier in Alibaba,
4: The key enterprises of " 11th Five-Year Plan"
package & shipping
Packaging
A: barreled package+outer carton+pallets
B: single box+outer carton+pallets
C: tube package+middle box+outer carton+pallets
D: According to your requirement
