Car Wheel Bearing 51413 Thrust Bearing 51413 Bearing 65*140*56mm

Car Wheel Bearing 51413 Thrust Bearing 51413 Bearing 65*140*56mm thumbnail-1
Car Wheel Bearing 51413 Thrust Bearing 51413 Bearing 65*140*56mm photo-1
US$ 6 - 6 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Brand Name:
CLUNT, CLUNT
Bore Size:
65,
Outside Diameter:
140,
Contact Supplier Request Quote Chat Now
Jinan Kelunte Bearing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name CLUNT, CLUNT
Bore Size 65,
Outside Diameter 140,
Model Number 51413
Precision Rating P0,P4,P5,P6
Seals Type Wooden Packing
Number of Row Other, single row or double rows
Place of Origin Tianjin, China

Specifications

bearing 51409
1)ID.65mm
2)Material:GCr15,GCr15SIMn
3)Quality Stander:ISO9001:2008
4)High quality,Lower price

car wheel bearing 51413 thrust bearing 51413 bearing 65*140*56mm

Thrust ball bearing product decription:



Thrust ball bearings typically consist of two races/rings and a complement of balls. The balls may be loose between the races but are more typically retained. The retainers used are defined by the intended use and may be composed of steel, bronze, ceramic or elastomeric elements.

 They can be supplied with or without radius ball grooves in the rings. Thrust bearings should be used under purely axial loads.

car wheel bearing 51413 thrust bearing 51413 bearing 65*140*56mm details:

Bearing Type Thrust Ball Bearings
Bore Dia (d) 65mm
Outer Dia (D) 140mm
Width (B) 56mm







51413 thrust ball bearings are manufactured as single direction or double direction, bearing 51413 is single direction bearing, as the name suggested, this single direction bearing can only accommodate axial loads and locate a shaft axially in one direction only.

car wheel bearing 51413 thrust bearing 51413 bearing 65*140*56mm drawing&Installation

car wheel bearing 51413 thrust bearing 51413 bearing 65*140*56mm

51413 radial bearing shaft or housing can not be constrained to move in one direction but can be constrained axial movement of the shaft and housing, so often associated with this type of bearing deep groove ball bearing joint use. When 51413 bearing device axis of the shaft and housing bore is necessary to adhere to the concentric, or because of stress concentration will lead to premature bearing damage. In order to eliminate the bad appearance, can stay here the radial gap between the outer diameter of 0.5 ~ 1mm circle and shell holes. Migraine pain sets installed. First 51,413 condoms bearing partial pain on the inner sleeve bearing partial pain level, along the axis of rotation and hand tighten. Then a small iron bar against migraine pain pierce or sink hole sleeve. Direction along the axis of rotation by hand percussion hammer small iron bar. Hexagon screw migraine pain so sets of equipment firm, eventually locking sleeve migraine pain



car wheel bearing 51413 thrust bearing 51413 bearing 65*140*56mm Industry:



Horizontal reducer mold tile mechanical fume purification equipment dust cloth plastic machine plastic extruder elemental analyzer spray dryer mining drilling equipment fruit and vegetable processing equipment medical vehicles, beds, Taiwan hollow paddle dryer chemical pump reboiler painting equipment coffee equipment rework station metal packaging machinery cutting equipment industrial sewing shoe repair equipment and materials testing machine textile accessories bending machine drilling machine flexo printing machine drill sets concrete mixing equipment food machinery

car wheel bearing 51413 thrust bearing 51413 bearing 65*140*56mm catalog:



main dimension Basic load ratings  Fatigue load limit Minimum load factor Speed rating  Mass Designation
d D H C  C0 Reference speed limiting speed
Pu A
mm kN kN   r/min kg
25 60 24 55, 3 96, 5 3, 6 0, 048 3600 5000 0, 34 51405
30 70 28 72, 8 137 5, 1 0, 097 3000 4300 0, 52 51406
35 80 32 87, 1 170 6, 2 0, 15 2600 3800 0, 74 51407
40 90 36 112 224 8, 3 0, 26 2400 3400 1, 10 51408
45 100 39 130 265 9, 8 0, 37 2200 3000 1, 42 51409
50 110 43 159 340 12, 5 0, 60 2000 2800 2, 00 51410
55 120 48 195 400 14, 3 0, 79 1800 2400 2, 55 51411
60 130 51 199 430 16 0, 96 1600 2200 3, 10 51412
65 140 56 216 490 18 1, 2 1500 2200 4, 00 51413
70 150 60 234 550 19, 3 1, 6 1400 2000 5, 00 51414
75 160 65 251 610 20, 8 1, 9 1300 1800 6, 75 51415
80 170 68 270 670 22, 4 2, 3 1200 1700 7, 95 51416
85 180 72 286 750 24 2, 9 1200 1600 9, 45 51417
90 190 77 307 815 25, 5 3, 5 1100 1500 11, 0 51418
100 210 85 371 1060 31, 5 5, 8 950 1400 15, 0 51420
110 230 95 410 1220 34, 5 7, 7 900 1300 20, 0 51422
120 250 102 520 1730 45 16 800 1100 29, 5 51424
130 270 110 520 1730 45 16 750 1000 32, 0 51426
140 280 112 520 1730 44 16 700 1000 34, 5 51428
150 300 120 559 1960 48 20 670 950 42, 5 51430



car wheel bearing 51413 thrust bearing 51413 bearing 65*140*56mm pictures:

car wheel bearing 51413 thrust bearing 51413 bearing 65*140*56mmcar wheel bearing 51413 thrust bearing 51413 bearing 65*140*56mmcar wheel bearing 51413 thrust bearing 51413 bearing 65*140*56mmcar wheel bearing 51413 thrust bearing 51413 bearing 65*140*56mmcar wheel bearing 51413 thrust bearing 51413 bearing 65*140*56mmcar wheel bearing 51413 thrust bearing 51413 bearing 65*140*56mmcar wheel bearing 51413 thrust bearing 51413 bearing 65*140*56mmcar wheel bearing 51413 thrust bearing 51413 bearing 65*140*56mmcar wheel bearing 51413 thrust bearing 51413 bearing 65*140*56mmcar wheel bearing 51413 thrust bearing 51413 bearing 65*140*56mm

car wheel bearing 51413 thrust bearing 51413 bearing 65*140*56mm
