Home > Industrial Equipment & Components > Bearing > Angular Contact Ball Bearing > Ball Bearings 71908 With Jinan Factory

Ball Bearings 71908 With Jinan Factory

Name: Ball Bearings 71908 With Jinan Factory
Brand: CLUNT
SKU: 139929015
Availability: InStock

Ball Bearings 71908 With Jinan Factory thumbnail-1

Ball Bearings 71908 With Jinan Factory photo-1

US$ 12 - 12 MOQ: 10 Sets

Key Specifications

Get Latest Price

Brand Name:

CLUNT

Bore Size:

40,

Outside Diameter:

62,

Contact Supplier Request Quote Chat Now

Jinan Kelunte Bearing Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Brand Name CLUNT

Bore Size 40,

Outside Diameter 62,

Model Number 71908

Precision Rating P0 P6 P5 P4 P2

Seals Type OPEN

Number of Row Single Row

Place of Origin Shandong, China

ball bearings 71908 with jinan factory

Dimensions - d (inside diameter)	Dimensions - D (outside diameter)	Dimensions - B (width)
40mm	62mm	12mm
Brand	CLUNT Bearing
Bearing Type	Angular contact ball bearing
Brand Model	CLUNT

Size: 71908
type: high precision angular contact ball bearing
Country: China
Brand: CNN
d: 40mm
D: 62mm
B: 12mm
C: 12.4kN
Co: 8.5kN
Pu: 0.36kN
grease: 20000r/min
oil-air: 34000r/min
Mass: 0.11kg

71908 CD/P4A
71908 CE/HCP4A
71908 CE/P4A
71908 DB/P7
71908 FB/P7
C71908 DB/P7
C71908 FB/P7
S71908 ACD/HCP4A
S71908 ACD/P4A
S71908 CD/HCP4A
S71908 CD/P4A
S71908 DB/P7
S71908 FB/P7
SC71908 DB/P7
SC71908 FB/P7
7008 ACD/HCP4A
7008 ACD/P4A
7008 ACE/HCP4A
7008 ACE/P4A
7008 CD/HCP4A
7008 CD/P4A
7008 CE/HCP4A
7008 CE/P4A
7008 DB/P7
7008 FB/P7
C7008 FB/P7
S7008 ACD/HCP4A
S7008 ACD/P4A
S7008 CD/HCP4A
S7008 CD/P4A
S7008 DB/P7
S7008 FB/P7
SC7008 DB/P7
SC7008 FB/P7
7208 ACD/HCP4A
7208 ACD/P4A
7208 CD/HCP4A
7208 CD/P4A
71809 ACD/HCP4
71809 ACD/P4
71809 CD/HCP4
71809 CD/P4
71909 ACD/HCP4A
71909 ACD/P4A
71909 ACE/HCP4A
71909 ACE/P4A
71909 CD/HCP4A
71909 CD/P4A
71909 CE/HCP4A

71908 Angular Contact Ball Bearings) may also bear radial load and axial load. Be able to work at a high speed. Contact angle the greater the higher the axial load capacity. High-precision and high-speed bearings usually take 15-degree contact angle. In the role of the axial force, the contact angle will increase. Single row angular contact ball bearings can withstand axial load in one direction, in the radial load, will cause additional axial force. And can only be restricted shell axis or the axial displacement in one direction. If pairs of double-installed, so that a pair of bearing outer ring relative, that is, the face of wide-side wide face, narrow end of a narrow face to face. This can avoid additional axial force, but also in both directions so that shaft or housing to limit axial clearance range.
Angular contact ball bearing raceway for its inside and outside the circle on the horizontal axis can be a relative displacement, so it can also bear radial load and axial load - the joint load (single row angular contact ball bearings can only bear axial load in one direction, Therefore, often used in pairs are generally installed).

d D B

71900C/AC	10	22	6
71901C/AC	12	24	6
71902C/AC	15	28	7
71903C/AC	17	30	7
71904C/AC	20	37	9
71905C/AC	25	42	9
71906C/AC	30	17	9
71907C/AC	35	55	10
71908C/AC	40	62	12
71909C/AC	45	68	12
71910C/AC	50	72	12
71911C/AC	55	80	13
71912C/AC	60	85	13
71913C/AC	65	90	13
71914C/AC	70	100	16
71915C/AC	75	105	16
71916C/AC	80	110	16
71917C/AC	85	120	18
71918C/AC	90	115	18
71919C/AC	95	130	18
71920C/AC	100	140	20
71921C/AC	105	145	20
71922C/AC	110	150	20
71924C/AC	120	165	22
71926C/AC	130	180	24
71928C/AC	140	190	24
71930C/AC	150	210	28
71932C/AC	160	220	28
71934C/AC	170	230	28
71936C/AC	180	250	33
71938C/AC	190	260	33
71940C/AC	200	280	38
71944C/AC	220	300	38
71948C/AC	240	320	38
71952C/AC	260	360	46
71956C/AC	280	380	46
71960C/AC	300	420	56
71964C/AC	320	440	56
71968C/AC	340	460	56
71972C/AC	360	480	56
71976C/AC	380	520	65
71980C/AC	400	540	65
71984C/AC	420	560	65
71988C/AC	440	600	74
71992C/AC	460	620	74

CLUNT certificate

CLUNT factory

Jinan Kelunte Bearing Co., Ltd. is a professional bearing manufacturer and is engaged in the imported bearings.
Our company is engaged in the imported bearings,company's main imported Roller Bearing,Ball Bearing,deep groove ball bearings,taper roller bearings,angular contact ball bearings,Pillow Block Bearing,Ceramic Bearing,cylindrical roller bearing, spherical roller bearing .

Packaging & Shipping

1. Neutral Package: Plastic Tube + Carton + Pallet

2. Commercial Package: single CLUNT Box + Carton + Pallet

1. Payment:

1) TT, 30% deposit , 70% before shippment.
2) L/C at sight. (high bank charge, not suggest , but acceptable )
3) 100% Western Union in advance. (specially for air shipment or small amount)

2. Delivery:

1) Less than 45 KGS, we will send by express. ( Door to Door, Convenient )

2) Between 45 - 200 KGS, we will send by air transport. ( Fastest and safest, but expensive )

3) More than 200 KGS, we will send by sea. ( Cheapest, but long time )

CLUNT market

FAQ

1.Why I choose you?

Profession and reliability. Everyone likes to blow big bubbles. But we need to be honest with ourselves. We maybe not the most handsome, but we have a heart like fire. To meet the morning sunshine, to enjoy our work every day. Say what we mean and mean what we said is our words to ourselves. We work for our family.

2.How long are their lifetime?

My friend, with your gentle care,6 months to 36 months for different products.

3.How to deal with the quality problem?

Congratulation! You must be winning lottery!

You will get helps by beautiful ladies from our QC terms. There will be discount, secret gifts, of course the new bearings waiting for you.On the other hand, we have a PPAP of each shipment, so that we knowWhich shipment is bad? We will cut off production line and avoid more loss.

4.Can you take responsibility for me?

Of course, I’m happy to help you! But I just take responsibility for my products. We are not willing to see the quality issues, but if happen this problem we will deal with them according to the actual situation.
