25mini tractor/small tractor/small farm tractor

Model

YTO-180

YTO-200

YTO-SE250

Diesel engine

Model

TY295IT

TY295IT

TY2100IT3

Type

Double cylinder, vertical, water cooled, four stroke

Displacement (L)

1.49

1.49

1.65

Rated power/speed(Kw)/(r/min)

13.2/2200

14.7/2200

18.4/2300

Max. torque (N.m)/speed (r/min)

66.4/1760

71.5/1760

86/1760

Bore x stroke (mm)

95x105

95x105

100x105

Transmission

Gear shift, forward/backward

16/4

16/4

8/4

Speed range (Km/h), forward/backward

2.64~27.0/1.05~9.79

2.71~27.44/1.03~10.07

2.17~28.13/2.59~7.86

PTO power (Kw)

10.56

11.77

15.5

PTO rotation speed(r/min)

540

540

540 or 720

Clutch

Single disc

Single disc

Single disc

Implement

Three-point linkage category

Rear three- point linkage 0

Rear three- point linkage 0

Rear three-point linkageⅠ

Tilling depth control mode

Height adjustment

Height adjustment

Floating adjustment, position adjustment

Lifting force(KN)

2.98

3.2

4.2

Dimensions, mass, drive

Drive type

4x2

4x2

4x2

Overall dimensions (LxWxH)(mm)

2540x1205x1370

2800x1240x1400

2935x1230x1418

Wheelbase(mm)

1440

1500

1630

Min. ground clearance(mm)

271

305

325

Min. operating mass(with safety stand)(Kg)

1060

1060

1170

Tyre spec., front /rear

4.0-14/7.5-20

4.0-14/9.5-20

4.0-16/9.5-24

Wheel tread, front/rear

1000/1000

1000/1020

1080/1020

Steering

Mechanical

Brake

Shoe, mechanical
