Specifications
1.Hydraulic parts supplied by the world's famous supplier2.Used in loading wood or sugarcane,recycling waster of paper etc
Mini excavator variant product cane wheel loader DLS880-9A for sale
Main Features:
1. Hydraulic Matching Parts
Supplied by the world’s famous brand supplier for rotary motor/main valve/gear pump and relevant parts.
2. Joint
Being used of products by EATON company of top 500 in the world for its high reliability in kinds of bad working condition and resistance to shake or loose.
3. structural element
Using high quality 16Mn steel in domestic,meanwhile,the technology of welding has been reached to the international standard for its continuously increasing structural strength to make the driving and operational safety.At painting side, after shot blasting treatment,the adhesive capacity has been strengthened and delaying the rust ,then improving the working life of the device.
4. Control monitor
Timely feedback when machine going wrong in running conditions by its CPU supervisory system and also it can offer intelligent protection for starting motor.
5.Radiator
Using the brazing technique with finned pipe for promoting turbulence to reduce the flow resistance of hydraulic oil .Because of its improving heat transfer factor , we can working smoothly ,even in hot summer .
6.Travel
Travelling mechanism is made of the advanced mechanical drive in domestic.Due to its higher speed ,the machine can be transferred by itself in long-distance. In this way ,we can save the money for transfer ,meanwhile,it’s convenient to be repaired.
7.Steering system
Using the high quality steering cylinder to keep the machine smooth and steady in the running condition.
8.Wide-range in used
Being widely used in loading wood or sugarcane,meanwhile,can be also used in the field of recycling waster of paper and metal and treatment of urban garbage.Being truly realized multi-function with the same one.
Main parameters:
Model |
DLS880-9A |
|
Performance parameters | ||
Operating weight |
Kg |
7500 |
Bucket weight |
Kg |
390 |
Rated power |
Kw/rpm |
48/2300 |
Max. torque |
N.m/rpm |
230/1800 |
Operating pressure |
Mpa |
21 |
Rated flow |
L/min |
55X2 |
Pump delivery |
ml/r |
25X2 |
Travel speed |
Km/h |
30 |
Swing speed |
rpm |
9.2 |
Max.traction force |
KN |
43.2 |
Gradeability |
° |
20 |
Fuel tank |
L |
125 |
Hydraulic oil tank |
L |
105 |
Working range | ||
Max.loading weight |
Kg |
500 |
Max.loading range |
mm |
6758 |
Max.dumping height |
mm |
4721 |
Dimensions | ||
Overall length |
mm |
6321 |
Overall width |
mm |
2000 |
Overall height (Cab top) |
mm |
2710 |
Overall height(boom top) |
mm |
2730 |
Under balance weight ground clearance |
mm |
985 |
Min. ground clearance |
mm |
280 |
Wheelbase |
mm |
2310 |
The distance between the both side tyre |
mm |
1560 |
Dozer blade width |
mm |
2024 |
Dozer blade height |
mm |
310 |
Boom length |
mm |
3500 |
Arm length |
mm |
2000 |
Opening dimension |
mm |
1266 |
Outline dimension of grab bucket |
mm |
1500x1020x1600 |
If you are interested in it, feel free to contact me immediately.
