Help CenterChinese Imported Components Small Excavator WY6-3 for Sale With 5.8 Ton
Related Products
-
Chinese Imported Components WY6-3 Mini Hydraulic Excavator for Sale With 5.8 TonUS$ 42,900 - 45,500MOQ: 1 Unit -
YTO WY6-3 6ton Mini Crawler Excavator for SaleUS$ 41,600 - 43,600MOQ: 1 Unit
-
Chinese Imported Components WY6-3 Crawler Hydraulic Excavator for Sale With 5.8 TonUS$ 42,900 - 45,500MOQ: 1 Unit
-
Chinese Imported Components WY6-3 Crawler Excavator for Sale With 5.8 TonUS$ 42,900 - 45,500MOQ: 1 Unit
-
Chinese Imported Components WY6-3 Hydraulic Excavator for Sale With 5.8 TonUS$ 42,900 - 45,500MOQ: 1 Unit
Specifications
1.Original YANMAR engine2.Hydraulic pilot valve system
3.Suitable for operation in the narrow
4.Turning around 360 angle
Chinese imported components small excavator WY6-3 for sale with 5.8 ton
Main Features:
1.The original imported engine is used, featured in low fuel consumption and low noise and also it can reach the standard of Euro II.
2. The variable and operable hydraulic system is applied as it features advanced technology and high reliability.
3. With excellent outline, full enclosed, large-vision, the cab is equipped with air conditioning (for cooling/heating ) and sound equipment
4. Many kinds of monitor display and function-control system are centralized in the intellectualized minitype control-panel.
5. With the advantages of lightly and conveniently operating, accurate control, the hydraulic pilot valve system can achieve the elaborate work.
6. Holding the core concept of “excellent performance for high efficiency operation” , the excavator is suitable for the operation in the narrow place for its small volume and turning around 360 angle.
Product Parameters:
Model |
unit |
WY6-3 |
Operating weight |
kg |
5800 |
Bucket capacity |
m3 |
0.22 |
Length/width/height |
mm |
5950×1920×2620 |
Engine model |
YANMAR 4TNV98-SSU |
|
Rated power/speed |
kW/r/min |
43.4/2200 |
Fuel consumption |
g/kw.h |
≤247 |
Fuel tank capacity |
L |
90 |
Rated flow |
L/min |
170 |
Implementation circuit |
Mpa |
22 |
Swing speed |
r/min |
0-10 |
Bucket digging force |
kN |
40 |
Arm digging force |
kN |
25 |
Max.traction force |
kN |
58.5 |
Traveling speed |
km/h |
0-2.3/0-4.4 |
Gradeability |
° |
30 |
Ground pressure |
kPa |
33 |
max.digging radius |
mm |
6150 |
max.digging height |
mm |
5515 |
max.dumping height |
mm |
3730 |
max.digging depth |
mm |
3820 |
overall length |
mm |
5950 |
crawler length |
mm |
2590 |
Wheelbase |
mm |
1990 |
counter weight ground clearance |
mm |
740 |
overall height |
mm |
2620 |
tail turning radius |
mm |
1650 |
roof width |
mm |
1850 |
crawler height |
mm |
645 |
min.ground clearance |
mm |
325 |
crawler width |
mm |
400 |
Crawler gauge |
mm |
1520 |
chassis width |
mm |
1920 |
earth-moving shovel(width/height) |
mm |
1920×320 |
