Agricultural machinery: tractors, harvesters, rotary machines, balers, shredders, transplanter, agricultural transport vehicles;
Corresponding products: shaft, friction torque, a spline fork, slide the fork, spline shafts, Pipes, universal joints, cross shaft, etc.;
1.With CE certificate
2.Forged yoke
3.Use for 15-120HP
4.Multi-tooth spline. Specifications from the 1 3 / 8 "Z6, 1 1 / 8" Z6, 1 3 / 4 "Z6, 1 3 / 8" Z20, 1 1 / 8 "Z20, 1 3 / 4" Z20, 1 3 / 8 "Z21 , 1 1 / 8 "Z21, 1 3 / 4" Z21, etc., complete specifications are welcome.
5.Triangle shaped tube, lemon tube, pipe welding fork Star,sqare tube .
PTO shaft's universal joint Characteristics
1. Material: 20Cr or 20CrMnTi
2. Surface Hardness: 58-64HRC
3. Core hardness:20Cr: 25-45HRC / 20CrMiTi: 33-48HRC
PTO drive shaft for different brands of agriculture machinery, such as tractor Johndeer, case,and newholland
| Item | Cross journal size | 540dak-rpm | 1000dak-rpm | |||
| Series 1 | 22mm | 54mm | 12KW | 16HP | 18KW | 25HP |
| Series 2 | 23.8mm | 61.3mm | 15KW | 21HP | 23KW | 31HP |
| Series 3 | 27mm | 70mm | 26KW | 35HP | 40KW | 55HP |
| Series 4 | 27mm | 74.6mm | 26KW | 35HP | 40KW | 55HP |
| Series 5 | 30.2mm | 80mm | 35KW | 47HP | 54KW | 74HP |
| Series 6 | 30.2mm | 92mm | 47KW | 64HP | 74KW | 100HP |
| Series 7 | 30.2mm | 106.5mm | 55KW | 75HP | 87KW | 18HP |
| Series 8 | 35mm | 106.5mm |
70KW | 95HP | 110KW | 150HP |
| Series 38 | 38mm | 102mm | 70KW | 95HP | 110KW | 150HP |
Advantages / Features:
1. Materials:
Our company has purchased steel from several large steel groups , such as Hangzhou Steel Mill, Shanghai Bashan Steel Mill, Beijing Shrugging Steel Mill whose steel have good mechanical properties and stability of chemical component. it keep the shaft to be of high quality.
2. Manufacture Procession
First, we have our own High-precision Digital Machining center for mould making in special Mould Workshop, excellent mould make product beautiful appearance and its size accurately.
The second, we adopt blasting procession, removing Oxidation surface, make the surface to be bright and clean and uniform and beautiful.
The third, in heat treatment: We use the Controlled-atmosphere Automatic heat treatment Furnace,
3. Quality Control:
The quality control is strictly performed from buying raw materials in warehouse to different machining procession and to final packing. 100% inspection during production .
4. Production Capacity
Single PTO shaft , every month can produce 9000 pcs.
Goals of Global Sourcing at PAPAYA:
Reduce purchasing costs
Increase the quality
Reduce risks within the supply chain
Secure innovations of top suppliers worldwide
