Home > Industrial Equipment & Components > Fastener & Fitting > Bolts > Hexagon Bolt

Hexagon Bolt

Name: Hexagon Bolt
Brand: PAPAY
SKU: 139914065

US$ 0.1 - 1.5 MOQ: 1 Ton

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

PAPAY

Model Number:

M6-M100

Contact Supplier Request Quote Chat Now

Hangzhou Papaya Trading Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai or ningbo port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name PAPAY

Model Number M6-M100

Specifications

hexagon bolt
1.Hot foring,
2.Size: M16~M100
3.Finish:plain, black ,zinc plated, hot dip galva

washerM16.M18.M20.M24.M27.M3,M36

High-Strength Structural Bolting DIN EN 14399

1.Grade:10.9

2.Size:M12~M42, Length :30MM~400MM

3.Standard: DIN EN14399 -4&6

3.Finish: HDG, Phosphating ,Black,Dacromet,etc.

4. Widely used in wind power system,construction bridges, steel structural of boilers, industrial buildings, tower mast steel structure , lifting machines, etc.

5.Packing: Standard export packing or According to customer's requirement

Use the top grade raw material,Through ultrasonic flaw detection,chemical composition analysis,

spectroscopic analysis,mechanical property test and spark discrimination detecting,

completely rejects any mixed raw material,and keep the material selection complying to
standard requiremnt

Management Standard:
• ISO9001:2001 • ISO/TS16949

Production Standard:
• Din 6914, Din 6916, Din 7990, Din 7999
• Non-Standard

Finish Treatment:
• Zinc Clear, Zinc Yellow,
• Nickel-plating, in-plating, Chrome-plating,
• Dacromet, Black
• Mechanical Galvanizing
• Hot-dip Galvanizing etc.

Material used:
• Carbon Steel • Alloy Steel
• Stainless Steel • Copper
• Aluminum • Brass

Thread Types:
• Typically metric coarse and metric fine
• British Standard Whitworth (BSW)
• British Standard Fine (BSF)
• Unified National Coarse (UNC)
• Unified National Fine (UNF)
• Unified National Series
• Coach screw thread form

Manufacturing

Portland Bolt manufactures hex bolts from 1/2" diameter through 2-1/2" diameter in most ASTM, AASHTO, and SAE specifications. Special tooling can be created to produce nonstandard head dimensions or bolt heads with your company's name and/or logo.

.

Dimensions

Bolt Diameter	D	F			C		H
	Body Diameter	Width Across Flats			Width Across Corners		Height
	Max	Basic	Max	Min	Max	Min	Basic	Max	Min
3/8	0.388	9/16	0.562	0.544	0.650	0.620	1/4	0.268	0.226
1/2	0.515	3/4	0.750	0.725	0.866	0.826	11/32	0.364	0.302
5/8	0.642	15/16	0.938	0.906	1.083	1.033	27/64	0.444	0.378
3/4	0.768	1-1/8	1.125	1.088	1.299	1.240	1/2	0.524	0.455
7/8	0.895	1-5/16	1.312	1.269	1.516	1.447	37/64	0.604	0.531
1	1.022	1-1/2	1.500	1.450	1.732	1.653	43/64	0.700	0.591
1-1/8	1.149	1-11/16	1.688	1.631	1.949	1.859	3/4	0.780	0.658
1-1/4	1.277	1-7/8	1.875	1.812	2.165	2.066	27/32	0.876	0.749
1-3/8	1.404	2-1/16	2.062	1.994	2.382	2.273	29/32	0.940	0.810
1-1/2	1.531	2-1/4	2.250	2.175	2.598	2.480	1	1.036	0.902
1-3/4	1.785	2-5/8	2.625	2.538	3.031	2.893	1-5/32	1.196	1.054
2	2.039	3	3.000	2.900	3.464	3.306	1-11/32	1.388	1.175
2-1/4	2.305	3-3/8	3.375	3.262	3.897	3.719	1-1/2	1.548	1.327
2-1/2	2.559	3-3/4	3.750	3.625	4.330	4.133	1-21/32	1.708	1.479

Goals of Global Sourcing at PAPAYA:

Reduce purchasing costs
Increase the quality
Reduce risks within the supply chain
Secure innovations of top suppliers worldwide
