Supply From Stock! BW Series Orbit Hydraulic Motor

FOB Price

USD $10 - $299 / Set

1 Set(Min.Order)

Supply Ability 1000 Set / Sets per Month
Port China main port
Payment Terms:T/T Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Type:	Hydraulic Motors	Model Number:	hyd1raulic motor	Brand Name:	JSD
Place of Origin:	Hebei, China

Product Description

BM Series Obit Hydraulic Motor

(Supply from stock)

BV Certificated Company with Main Products Line Checked
Paid Membership of
ISO 9001 Quality Manage System

Product Description

BMS (LMP)
(ml/r)Displacement		50	63	80	100	125	160	200	250	315	400
(LPM)Flow	Max.Cont..	38	45	58	58	58	58	58	58	58	58
(LPM)Flow	Int..	45	53	69	69	69	69	69	69	69	69
(RPM)Speed	Max.Cont..	698	663	685	560	456	356	285	236	179	145
(RPM)Speed	Int..	858	775	820	671	548	426	341	282	210	173
(Mpa)Pressure	Max.Cont	12.5	12.5	12.5	12.5	12.5	11	10	10	9	9
(Mpa)Pressure	Int..	14	14	14	14	14	12.5	12.5	12.5	12.5	11
(N*M)Torque	Max.Cont.	74	87	124	155	194	227	282	302	365	456
(N*M)Torque	Int..	86	98	141	176	221	260	318	383	406	521

BM3(LM3)
(ml/r)Displacement		100	160	200	250	315	400
(LPM)Flow	Max.Cont..	50	50	50	50	50	50
(LPM)Flow	Int..	60	60	60	60	60	60
(RPM)Speed	Max.Cont..	450	281	226	180	147	121
(RPM)Speed	Int..	540	337	272	216	177	142
(Mpa)Pressure	Max.Cont	14	12.5	12.5	12	12	11
(Mpa)Pressure	Int..	16	14	14	13	13	12.5
(N*M)Torque	Max.Cont.	178	272	330	392	499	581
(N*M)Torque	Int..	216	306	357	424	540	660

LM4
(ml/r)Displacement		245	310	390	500	630	800
(LPM)Flow	Max.Cont..	80	80	80	80	80	80
(LPM)Flow	Int..	100	100	100	100	100	100
(RPM)Speed	Max.Cont..	320	250	200	156	120	106
(RPM)Speed	Int..	390	300	240	200	150	120
(Mpa)Pressure	Max.Cont	14	14	14	14	12.5	10
(Mpa)Pressure	Int..	15	15	15	15	13	12
(N*M)Torque	Max.Cont.	435	556	698	870	997	1024
(N*M)Torque	Int..	502	664	798	1058	1178	1380

LMS(bm5)
(ml/r)Displacement		80	100	125	160	195	245	305	395	500
(LPM)Flow	Max.Cont..	75	75	75	75	75	75	75	75	75
(LPM)Flow	Int..	85	95	95	115	115	115	115	130	130
(RPM)Speed	Max.Cont..	850	675	552	430	345	287	231	178	142
(RPM)Speed	Int..	956	855	700	660	529	423	347	308	246
(Mpa)Pressure	Max.Cont	17.5	17.5	17.5	17.5	17.5	17.5	15	15	12
(Mpa)Pressure	Int..	28	28	28	25	25	25	21	17.5	15
(N*M)Torque	Max.Cont.	178	223	278	356	445	557	580	715	720
(N*M)Torque	Int..	285	356	445	509	636	755	763	840	860

Other types can produce according to your requirements.

Products Show:

Packaging & Shipping

Company Information

Workshop Show:

Photoes of Industrial Fair:

Why Us:

BV Certificate of Main Products Line Checked
CE Certificate of Quality Checked
Paid Membership of
ISO9001 Certificate of Quality Control System

Our Services

After-sales Service
Quality Gurantee
High Quality
Fast Delivery

FAQ

Quality Qurantee: One Year

Quality Control: ISO9001 Quality Constrol System

Quality : CE Certificate

Inspection: Third Party Inspection Acceptable

Service: After-Sales Service

Credit: BV Certificate of Main Production Line Checked

MOQ: 1 Set

Sample: Available

Delivery: Fast

Payment:: T/T, L/C

OEM: Acceptable

Contact Us

Hebei Jinsidun (JSD) Co., Ltd.: Contact nameJackie Yan; Phone86-311-80979378; AddressDFMZ Buliding, Yuhua District, Shijiazhuang,China Shijiazhuang,Hebei
