HLS 35 concrete bacthing station seller
1. HLS 35 concrete batching station introduction
The system introduction
1.The mixer is reasonably designed with short mixing time low consumption, low noise and long service life
2.The mixing blade and lining board use wear resisting - material. They have long service lie and are convenient to dismantle and replace
3.The cylinder discharging is convenient and quick ..the hopper that fit the material mover is installed under the gate to make the quick discharging
Electric Control System
1 The operation is integrated with management .it is easy and convenient to operate
2 The batching system is controlled by the microcomputer
3 The operating data of the mixing plant can be saved for more than ten years for the convenience of setting management.
4.the dispensation formula which can reach more then dozens can expressed by the figures for the convenience of distinguishing.
5.t has the function of error analyzing and automatic testing functions .Under the condition departing from the automatic control .the manual operating system can finish the control of the mixing plant such as batching, mixing discharging.
6.Manual control system can finish the control of mixing plant without auto control.Such as mathing,mixing ,discharging
7 The strong current is integrated with the weak current
which simplify the installation and make the maintenance
much more convenient
2. HLS 35 concrete batching station main technical parameter
HZS 35 concrete mixing plant | ||
Model |
HZS35 |
|
Production(m3/h) |
35 |
|
Mixer |
|
JS750 |
power(kw) |
30 |
|
output(m3) |
0.75 |
|
grain size(mm) |
40 |
|
Batcher |
hopper capacity(m3) |
24 |
hopper quantity (pcs) |
3 |
|
Conveyor Capacity(T/h) |
150 |
|
Weighting Scope Accuracy |
aggregate(kg) |
2000±2% |
cement(kg) |
500±1% |
|
adulterant(kg) |
150±1% |
|
water(kg) |
250±1% |
|
admixture(kg) |
35±1% |
|
Total power(kw) |
≈70 |
|
Discharge height(m) |
3.8 |
|
If you are interested in ,pls feel free to contact Linda at +86-15264934636 Or add skype: linda112637
