Open Mouth Bag Multi-functional Bags Packing Machine is a most effective way to fill free flowing powders,granulates into open-mouth bags.
Open Mouth Bag Multi-functional Bags Packing Machine is an ideal solution for bulk filling free flowing powder & granules.
| Product Infeed | Gravity | Belt | Vibratory | Screw |
| Production Rate | up to 10 | up to 7 | up to 6 | up to 6 |
| System Accuracy | 0.5% | |||
| Bag Accuracy | ±150g typical @ 6 x 20kg bags/min (grain) | |||
| Weighing Range | 10-50Kg | |||
| Air Consumption | 1.5L per cycle | |||
| Weigh Hopper Capacity | 80, 100, 135 and 170 Litre | |||
| Operating Pressure | 4-6 bar ( 10 bar Max.) | |||
| Operating Temperature |
-5°C to 45°C |
|||
Notes: (Suitable for powders and granulates)
Factory in Australia
Factory in China
1, Production Rate can be up to 720bags per hour depending on product characteristics, bag weight, and accuracy needed.
2, High accuracy, reliable operation with stainless steel options, so it’s built to last.
3, The open-mouth bagging system is a semi automatic electronic bagging system available in standard patterns or customized to your requirements.
4, Enclosed design with removable panels providing easy access into the machine.
5, Choice of round dust-tight manual bag holding system for dusty applications or Hi Flo v-shape bag holding system (Duck Bill)
6, Manual adjustment of flow control & shut off gate Two stage flow control with SMART GATE technology.
7, Precision weigh hopper with Stainless Steel Hermetically Sealed IP68 Rating APE-7 loadcells.
8, Full safety guarding, ensures a safe working environment, which conforms to Australian andInternational safety standards.
9, Hi-flow bombay doors with empty sensing & auto refill.
10, Built for continuous operation 24 hours/day.
11, SOFT CLOSE clamps on our designs are fast and safe
12, Quick connect pneumatic and single phase electrical hookup
13, Also Controls overhead hopper (high and low) and bag closing line
FAQ
Why don't you answer the following questions for us to help you find what you want ?
1, the material you want to pack and its size(μm, mm), bulk density(kg/m3)
2, packing weight (kg/bag), capacity (t/day)
3, detailed description of production line
If you want to have more information about our machine , please contact me.
