Home > Manufacturing & Processing Machinery > Mixing Equipment > Concrete Mixer > High Efficient Double-shaft Compulsion JS2000 Concrete Mixer

High Efficient Double-shaft Compulsion JS2000 Concrete Mixer

Name: High Efficient Double-shaft Compulsion JS2000 Concrete Mixer
Brand: DASWELL
SKU: 139873193
Availability: InStock

High Efficient Double-shaft Compulsion JS2000 Concrete Mixer thumbnail-1

High Efficient Double-shaft Compulsion JS2000 Concrete Mixer photo-1

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

Place of Origin:

Henan, China

Brand Name:

DASWELL

Contact Supplier Request Quote Chat Now

Henan Daswell Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao Port China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Place of Origin Henan, China

Brand Name DASWELL

Model Number JS2000

Motor Power 2X37KW

Mixing Power 2X37KW

Charging Capacity 3000L

Reclaiming capacity 2000L

Speed of Mixing Drum 24.5r/min

Water Supply Mode Automatic water supply pump

Working Cycle Period 60s

Discharge Way Pneumatic or Hydraulic

Outline Dimension 3460x2320x2140mm

After-sales Service Provided Engineers available to service machinery overseas

High Efficient JS2000 Double-shaft Compulsion Concrete Mixer

Factory Photo

Technical Parameters

Model		JS1000	JS1250	JS1500	JS2000	JS2500	JS3000	JS3500	JS4000	JS4500
Discharging Volume(L)		1000	1250	1500	2000	2500	3000	3500	4000	4500
Charging Volume(L)		1500	1750	2250	3000	3750	4500	5300	6000	6750
Max. Aggregate Size (mm)		80/100	80/100	80/100	80/100	80/100	80/120	80/120	80/150	80/150
Weight(Ton)		5.20	5.50	5.80	7.50	8.50	9.20	9.60	12.20	12.50
Cycle Time(s)		≤ 60	≤ 60	≤ 60	≤ 60	≤ 60	≤ 60	≤ 60	≤ 60	≤ 60
Mixing Time(s)		≤30	≤30	≤30	≤30	≤30	≤30	≤30	≤30	≤30
Mixing Blades	Speed(r/min)	30	30	30	25	25	22	22	20	22
Mixing Blades	Quantity	10	12	14	14	16	18	20	22	22
Mixing Motor	Model	Y180M-4-B3	Y180-4-B3	Y200L-4-B3	Y225S-4-B3	Y225M-4-B3	Y250M-4-B3	Y250M-4-B3	Y280S-4-B3	Y280S-4-B3
Mixing Motor	Power(KW)	2x18.5	2x22	2x30	2x37	2x45	2x55	2x55	2x75	2x75

JS2000 double-shaft compulsion concrete mixer appearance and installation dimensions:

Brief Introduction

DASWELL JS series concrete mixer is twin-shaft compulsory mixer. Not only it can work independently, but also it can be adopted as the mixer in the high-end concrete batching plant.

It has the advantages of high efficiency, good mixing, compact structure, novelty appearance, easy to install, no leakage problem, less maintenance work, etc, it has won good reputation from our customers.

Features of double-shaft compulsion concrete mixer

1. Shaft ends multi seal protection and air purge seal protection to efficiently prevent leakage.

2. Unique mixer monitoring system to monitor working conditions of gearbox, discharge door pump, and electronic lubrication pump.

3. Special electronic lubrication pump, 4 separate independent pump cores for direct oil feeding without dividing valve.

4. Multi-pipe water sparying system to ensure even water distribution.

5. Adopt Italian BONFIGLIOLI reducer, long service life, low noise, no leak.

Packaging and Shipping

Payment terms:

30% of total price shall be paid by T/T as down payment;

70% balance payment should be paid by T/T before delivery.

Delivery time:

10-15 working days after receiving down payment

Container Loading:

1 set JS2000 per 20 GP; 3 sets JS2000 per 40 GP for double-shaft compulsion concrete mixer

Our Services

How to Order?

About Us

Daswell Machinery is a company specializing in the research, design and production of construction for nearly 30 years. Our main products are construction machinery, such as concrete mixer, concrete batching plant, concrete pump, and so on.

With several researching and producing bases in China, we can provide the powerful technical service and upper quality machinery for the clients all over the world. All of our products are produced according to the International Quality Standards, such as CE from Europe. The management of our company is strictly operated by the ISO 9001 quality management system.
And also, we supply the famous brand concrete machinery and related parts,such as SICOMA,and WAM Brand. We have supplied so much famous brand machinery and parts to many countries of the world.
All of our Daswell people here will try our best to bring more value for our friends and partners from all of the world, by our top class machinery and service, all the time!
