2016 JS1000 Electric Concrete Mixer
Model |
JS500 |
JS750 |
JS1000 |
|
Discharging volume (L) |
500 |
750 |
1000 |
|
Charging volume (L) |
800 |
1200 |
1600 |
|
Capacity (m³/h) |
≥25 |
≥35 |
≥60 |
|
Max. Aggregate Size (mm) |
≤40/50 |
≤40/60 |
≤60/80 |
|
Cycle time (s) |
60 |
60 |
60 |
|
Discharge height (m) |
3.8 |
3.8 |
3.8 |
|
Weight (kg) |
4000 |
5500 |
8700 |
|
Mixing Blades |
Speed (r/min) |
35 |
26 |
29.6 |
|
Quantity |
2×7 |
2×7 |
2×8 |
Mixing Motor |
Model |
Y180M-4 |
Y200L-4 |
Y180M-4 |
|
Power (kw) |
18.5 |
30 |
2×18.5 |
Hoisting Motor |
Model |
YEZ132S-4 |
YEZ132M-4 |
YEZ160L-4 |
|
Power (kw) |
5.5 |
7.5 |
15 |
Water pump motor |
Model |
BL12-12-1.1 |
BL18-16-1.1 |
80JDB-45 |
Power (kw) |
1.1 |
1.1 |
3 |
|
1.Features of electric portable concrete mixer
1. As a miniature double-horizontal-shaft forced type concrete mixer, this concrete mixing machine features short mixing time, good homogeneity and reliable operation.
2. Shaft tip is sealed by floating-ring, which is reliable and easy to maintain and replace.
3. Working condition: Road, Bridge & Precast product for factory, work independently or be used with correspond batching machine as a mini-type concrete plant.
4. Discharge system: Hydraulic & manual mode, drive reposefully and low noise.
5. Inside Mixer: Liner and mixer blade adopts high rigidity wear resistant steel (long service life).
The electrical system adopts import component, from those world famous exporter which are reliability and have good performance.
2.Introduction of electric portable concrete mixer
DASWELL JS series concrete mixer is twin-shaft compulsory mixer. Not only it can work independently, but also it can work with PLD series aggregate batcher to make a simple concrete plant or is adopted as the mixer in the high-end concrete batching plant.
3.Application of electric portable concrete mixer
They are widely used to produce dry hard concrete, plastic concrete, flow concrete, light aggregate concrete, various mortars, etc. Suitable for all kinds of big, medium and small precast concrete plant; widely applied in roads, bridges, water projects or other industrial and civil projects.
4.Details of electric portable concrete mixer
After Sale Service
1. Free Technical support
2. Spare Parts Supply Timely
Quality Control
We successfully passed ISO 9001:2000 and CE certificate.
All of our products must be tested before leaving our factory.
About us
Henan Daswell Machinery Co., Ltd. is a manufacturer and trader specializing in the research, development and production of construction machinery for nearly 30 years.
We have gained a global sales network reaching in Colombia, Bolivia,Brazil,Venezuela, Ecuador, Russia, Philippines, Vietnam, Libya, Ghana, etc. In the tenet of Quality,Service and Excellence.
DASWELL MACHINERY is looking forward to cooperation with new and regular customers all around the world.
Henan Daswell Machinery Co., Ltd.
Tel:+86-371-656669681
If you have any interests about our products please contact us.
We will sincerely provide first-class products and great after-sale services.
