Specifications
2-side roll pallet:1)ISO9001:2000
2)SPARK brand
3)zinced finish (4"PP castors)
4)710*810*1660mm 2-sided roll pallet
2-side roll pallet:
A mobile roll pallet for the safe and secure transportation of a wide range of goods built upon a strongly constructed 'A' frame chassis to help safety.
The standard Roll Container model includes two, three or four sides and a rectangular floor all with robust ladder style framing and heavy duty rod infill (mesh infill also available).
Optional hinged or detachable shelves can be specified used in simple steps.
For convenience and ease of storage when not in use the sides can be folded.
Large numbers of 'A' frame roll cages can then be nested together by pushing the narrow part of the cage into the wider rear section of the next roll cage.
Equipment:
1: Plasma cutting machine
2: Skilled welding workers
3: Many years' experience in making large welding parts
4: Good engineers to estimate the prices
5: excellent wedling technology
6: boring machine
Roll Cage Finish
Bright electro-zinc plating with a lacquer coat as standard. Other finishes are available to order.
Shelves
Hinged or detachable with optional heights.
Roll Cage Wheels
125mm diameter nylon or tyred wheels with option of plain or roller bearings, with or without thread guards.
Roll Cage Finish
Bright electro-zinc plating with a lacquer coat as standard. Other finishes are available to order.
Shelves
Hinged or detachable with optional heights.
Roll Cage Wheels
125mm diameter nylon or tyred wheels with option of plain or roller bearings, with or without thread guards.
4)Finish: zinc-plated or hot-dip galvanized, powder-coated are the highest in hygienic quality.
Processing procedure:cold drawing meterial→calibrating→ stamping/folding→ cutting→welding/ robert-welding→electroplate→assembling→FINISH.
Fine Quality Standard:ISO9001:2000 export to Korea, Japan, USA, European countries,SouthEast Asia, etc.
Parameters:
1.Size:710*820*1860mm
2.Wheel:2 fixed 2 swivel 5" PP,PA or PU castors
3.Finish:electro zinc plated
4.Material:Steel square tube,round tube,steel wire,angle steel
5.Weld:manual welding,welding manipulator (carbon-dioxide arc welding)
6.Surface treatment:3 independent powder coated lines
Name |
Demountable logistic trolley with plywood base |
|
Model |
XHC-05 |
|
Size |
Dimention |
710*810*1660 |
Mesh dimension |
|
|
Material size |
Wire dia. |
4mm 5mm |
Thickness of pipe |
6mm |
|
Thickness of base |
metal base |
|
Material |
Steel bar,round tube,Square Steel Tube |
|
Wheel dia. |
100mm,125mm,150mm |
|
Wheels |
2 fixed 2 swivel 5" PP,PA or PU castors |
|
Finish |
Zinc galvanized or Powder coated |
|
Capacity |
500kg |
|
Package |
Common type:in bulk with some protection |
|
Packing quantity 40"HQ |
about 260 pcs |
|
Characteristic |
1.Steel metal frame |
|
2.Robust wire formed construction | ||
3.Foldable,save cost and space when shipping and storage | ||
4.Displays the products observably | ||
5.Express card,make the work flow clear and definite | ||
6.Lots of sizes to select | ||
7.Electro zinc plated after welding for rust-free life | ||
8.Hygienic - can be steamed cleaned or pressure washed | ||
