The surface finishing is zinc plated or colour zinc plated or powder coated.We have two sides,three sides,four sides,four sides add lid. If you require some plywoods and casters,we can assemble The products are used to USA,the United Kingdom,Sweden,Singapore,Japan and so on. We can produce them according to your design.
1.We have been in the logistics appliance for thirteen years.the main products are:
1).wire mesh container
2).roll cages/pallet
2.our products price is lower.
3.We have own mould factory.We can manufacture the products according to the clients' require
4.We have good experience at the items.3-sides Roll Cage is Durable Frame Folds Easily for Storage
XHC-09 Parameters |
UOM |
Info to be Provided |
Type of Roll Cage |
|
2-sided roll container |
No of Separators |
|
no |
Overall Height |
mm |
1700 |
Internal Height |
mm |
1550 |
Unload Weight of the Roll Cage |
Kg |
60kgs |
Outer Width of Roll Cage |
mm |
800 |
Inner Width of Roll Cage |
mm |
765 |
Outer Length of Roll Cage |
mm |
1100 |
Inner Length of Roll Cage |
mm |
1065 |
Identification Plate |
|
On request |
Top Lid |
|
no |
Separator |
|
No, but it can on request |
Construction |
|
|
Thickness of Outer Vertical Frame |
mm |
2.0mm |
Dia of Pipe |
mm |
2.0mm |
Wire Dia |
mm |
4.8/5.8mm |
Grid Size of Wire mesh |
mm |
On request |
Thickness of Bottom Frame |
mm |
2.0mm |
Load Carrying |
|
|
Load Carrying of Roll Cage |
Kg |
600kgs |
Load Carrying Capacity of Separator |
|
N.A |
Wheel |
|
|
Wheel Material |
|
PU |
Wheel Dia on Open Side |
mm |
150mm |
Wheel Dia on Closed Side |
mm |
150mm |
No of Wheels Fixed |
|
2 nos |
No of Wheels Swivel |
|
2 nos |
Swivel Wheel on - Open Side/ Closed Side |
|
Closed side |
Swivel with a brake |
|
On request |
Wheel Cover Available |
|
Yes |
Fitted with thread guards |
|
Yes |
Overall Wheel Height |
mm |
-_ |
Finish |
|
|
Final Finish |
|
Powder coated /zinc plating |
Qingdao Spark Logistics Applience CO.LTD, manufacturer in several kinds of logistic appliance. Our firm is one of the subsidiary of Qingdao Spark Group (Second Grade Enterprise of state,China 500 Top Machinery Enterprise),established in 1993, In Jan.2003,we had obtained ISO9001 AND 2000 upgrade certification.
We’re a well-experienced manufacturer and also an exporter for Logistic Applience.we are specialized in designing,manufacturing Supermaket and warehouse Appliance ---such as steeless mental dustbin,Display rack, Shopping carts,Warehouse Shelving, Mesh containers, palletatainer, Tooling carts, Household Shelving, Stamping parts, Plastic injects parts, etc.
