Concerte mixing equipment
Description of JS750 concrete mixer
The js750 concrete mixing machine is double-horizontal shaft concrete mixer , self loading and controlled by electric, have a high quality, which can mix dry concrete, plasticity concrete, flowability concrete, light aggregate concrete and various mortar. can be used independently or as host machine in concrete batching plant, and they are applicable to the normal construction project, road, bridge site, or concrete component factories.
Features of twin shaft concrete mixer:
1. Short mixing time, good homogeneity and reliable operation.
2. Shaft tip is sealed by floating-ring, which is reliable and easy to maintain and replace.
3. High working efficiency and long working life.
Technical parameters of JS series
Parameter Model |
JS500 |
JS750 |
JS1000 |
JS1500 |
|
Item |
|||||
Discharge volume |
500L |
750L |
1000L |
1500L |
|
Charging volume |
800L |
1200L |
1600L |
2400L |
|
Theoretical capacity |
≥25m3 |
≥35m3 |
≥50m3 |
≥75m3 |
|
Aggregate sizes |
≤60/80mm |
≤60/80m |
≤60/80mm |
≤60/80mm |
|
Working circle |
60s |
60s |
60s |
60s |
|
Mixing blade |
Speed |
35r/min |
30.5r/min |
25.5r/min |
23r/min |
Quantity |
2×7 |
2×8 |
2×8 |
2×9 |
|
Mixing motor |
Model |
Y180M-4 |
Y200L-4 |
Y225S-4 |
Y225M-4 |
Power |
18.5 kw |
30 kw |
37 kw |
45 kw |
|
Lifting motor |
Model |
YEZ132S-4 |
YEZ132M-4 |
YEZ160L-4 |
YZE180M-4 |
Power |
5.5 kw |
7.5 kw |
11 kw |
18.5 kw |
|
Pump motor |
Model |
50DWB20-8A |
65DWB35-5 |
KQW65-100 |
KQW65-100 |
Power |
0.75 kw |
1.1 kw |
3 kw |
3 kw |
|
Weight |
1500kg |
6150kg |
9880kg |
10960kg |
|
Dimensions (L x W x H) |
2960x2600x4400mm |
3100x3500x5620 mm |
4640x2250x2250 mm |
5058x2250x2440 mm |
|
Our advantages
1.The best concrete mixer manufacture in China.
2.Double horizontal forced concrete mixer
3.High efficiency
4.Used widely and good mixig
5.Automatic loading system
6.Automatic discharging device
7.Sell well at home and abroad
8.CE,ISO,SGS,BV
Pictures of js750
Inside pictures
We are supply JS mixer including: JS500,JS750,JS1000,JS1500,JS2000,JS3000,JS4000,ALSO JSS500,JSS750,JSS1000,JSS1500,JSS2000,JSS3000,JSS4000, that is two-shaft, two-spiral,so it's more effecient than other mixers
Our International Market
We have established overseas projects in 28 countries and regions. And we need your support to introduce our high quality product and service to your honored company and country.
We also supply:
Mixer(JDC series, JS series, JZ series), Tower crane,
Concrete batching plant, Construction elevator,
Station soil mixing station, Concrete mixing truck,
Batching machine, Screw conveyor,
Cement Silo, Block making machine etc.
Welcome to contact us for more information about our concerte mixing equipment
