SC200 2tons construction elevator for sale
SC/SCD200 double cage Construction Elevator is one new type product manufactured by our company,it is widely used
to vertical transport personnel and materials.This product’s characteristics are reasonable design, attractive
structure, stable performance, complete safe device, easy instillation and convenient maintenance, etc.
Brief introduction
SC200/200 double cage construction elevator, adjust to meshing gear and rack, external type, three transmission,
rated lifting capacity is 2 tons,and biggest hoisting height is 150 meters . This machine is equipped
with a national patent technology for safety device, if falling can brake automatically , the top drive unit
equipped on the cage, safe and reliable, and it is convenient to maintenance . The machine's hoisting
height up to 150 meters. This machine is widely used in construction, such as industrial and civil
construction, bridge construction, underground construction, large chimney construction and shipbuilding
and other places, suitable for vertical transport materials and personnel, as a permanent or semi-permanent elevator can also be used in warehouses, towers and other places.
Technical parameters
| Parameter | Unit | Model | ||||
| SC100 | SC100/100 | SC200 | SC200/200 | |||
| Rated capacity | kg | 1000 | 2×1000 | 2000 | 2×2000 | |
| Number of people | No. | 7~10 | 14~20 | 10~15 | 20~30 | |
| Rated lifting speed | m/min | 34 | 34 | 34 | 34 | |
| Free Standing Height | m | 50 | 50 | 50 | 50 | |
| Max.lifting height | m | 200 | 200 | 200 | 200 | |
| Motor power | kw | 2×11 | 2×2×11 | 3×11 | 2×3×11 | |
| Suspension cage inner size | m | 3×1.3×2.3 | 3×1.3×2.3 | 3×1.3×2.3 | 3×1.3×2.3 | |
| Main Chord | mm | 76 x 4.5 | 76 x 4.5 | 76 x 4.5 | 76 x 4.5 | |
| Dimension of Mast Section | mm | 650×650×1508 | 650×650×1508 | 650×650×1508 | 650×650×1508 | |
| Weight of Mast Section | kg | 150 | 150 | 150 | 150 | |
| Suspension cage inner size | m | 3.2×1.5×26 | 3.2×1.5×2.6 | 3.2×1.5×2.6 | 3.2×1.5×2.6 | |
| Main Chord | mm | 76 x 6.0 | 76 x 6.0 | 76 x 6.0 | 76 x 6.0 | |
| Dimension of Mast Section | mm | 800×800×1508 | 800×800×1508 | 800×800×1508 | 800×800×1508 | |
| Weight of Mast Section | kg | 180 | 180 | 180 | 180 | |
| Overall Weight | kg | 7000 | 13000 | 7000 | 13000 | |
| Safety Device | SAJ40-1.2 | |||||
Detail pictures show
Sketch map of construction elevator
More information
Our Service Clients
Our Clients includes those FORTUNE 500 companies like CHINA RAILWAY, CHINA SINOHYDRO,
CHINA METALLURGY, CHINA STATE CONSTRUCTION ENGINEERING, CAMCE and China national
top companies like CHINA SOUTH-TO-NORTH WATER PROJECT, CHINA MECHANICAL EQUIPMENT CORP etc.
Our International Market
We have established overseas projects in 28 countries and regions. And we need your support to
introduce our high quality product and service to your honored company and country.
We also supply:
Mixer(JDC series, JS series, JZ series),
Concrete batching plant,
Station soil mixing station,
Batching machine,
Silo,
Tower crane,
Construction elevator,
Concrete mixing truck,
Screw conveyor,
Block making machine etc.
Welcome to inquire us for more information, we will give you best service.
