4x60m Calcined Rotary Kiln

Specifications

4x60m Calcined Rotary Kiln
1.Capacity 2500TPD
2.Main Motor 315kw
3.Main Reducer ZSY630-35.5-I
4.Weight 487.5t

Rotary kiln is a kind of cement equipment which can be divided into cement kiln, metallurgy chemical kiln and lime kiln according to the nature of materials. Cement kiln is used to make cement clinker, by using dry or wet method. Metallurgy chemical kiln is used in metallurgy industry and ironworks for lean iron ore, chromium ore and ferronickel ore calcimine. Rotary kiln can also be used to make calcimine of ochre in refractory material industry, calcimine of aluminum hydroxide in aluminum manufacturing

 plant, and chrome sand ore and chrome powder ore in chemical plant.

Characteristics of Rotary Kiln:

1. Rotary kiln is a kind of pyroprocessing device mainly used to sinter cement clinker. Both dry process and wet process are applicable.

2. It is widely used in metallurgy industry, chemical industry, cement industry, building industry, etc.

3. As a professional rotary kiln manufacturer in China, we adopt advanced contact type graphite block sealing device and hydraulic catch wheel device to ensure the stable running of kiln.

4. Through precision measuring and infra-red scanning, the whole sintering process can be monitored.

5. Our rotary kiln has the features of reliable performance, easy operation, low energy consumption, and high productivity, etc.

6. Compared to the output and energy consumption of other equipment of the same specification, the output of our rotary kiln has increased by 6-10% and energy consumption has reduced by 16%.

Specification:



Model	Capacity(T/D)	Main Motor		Main Reducer		Weight(T)
		Power	Model	Model	Speed Ratio
Ø1.9/1.6×39m	72	30	JZT2-72-4	JZQ750-I-Z	48.57	66
Ø1.9×36m	84	37	YCT315-4A	ZS110-5-III	78.19	85.9
Ø2.2×45m	98.4	55	JZT82-6	ZA125	93.93	104
Ø2.5/2.2×55m	120	40	JZT81	ZS145-10-I	134.9	197.2
Ø2.5/2.2×63m	108	40	JZT81	ZS145-10-I	134.9	170.5
Ø2.5×40m	204	40	Z2-92	ZS125-2-I	134.9	143.6
Ø2.5×45m	180	45	JZT82-4	ZS125-4-I	69.71	148
Ø2.5×50m		30	JZT372-4	ZS145-9-V	122.8	173
Ø3×48m	360-480	75	YCT355-48	ZS145-7-II	100.4	170.561
Ø3.1/2.5×78m	216-240	75	Z4-225-31	ZS165-2-II	57.17	267.6
Ø3.2×48m	1000	160	ZSN4-280-21B	NSY56-28-II	28	252
Ø3.2×50m	1000	160	ZSN4-280-21B	NSY56-28-II	28	263
Ø3.2×52m	1000	160	ZSN4-280-21B	NSY56-28-II	28	280.8
Ø3.3×50m	1200	160	ZSN4-280-21B	NSY450-28-V	28	317
Ø3.6×70m	492	125	Z2-112	ZS177	79.22	376
Ø3.95×80m	700	2×90	Z4-250-32B	NZS995	56	412
Ø4×50m	960	90	ZDT-11M	ZS220-3-IV	63.88	463
Ø4×60m	2500	315	ZSN4-355-09z	ZSY630-35.5-I	34.601	487.5
Ø4.2×60m	3000	420	ZSN4-355-12	ZSY710-35.5-I	35.526	576.1
Ø4.8×75m	5000	630	ZSN4-400-12	JSY-800-1760	31.5	841
