Specifications
cement clinker price1.Capacity150000-300000T/Y
2.Turnkey projector machinery supply
3.Exclusive design
Cement Grinding Station
Clinker grinding plant is a straight forward process. The clinker is transported to feed hopper, which feeds it into the Pre-crusher, Table feeders extract it out form the pre-crusher and feed it into a Ball mill, Blending of this fine powder with gypsum and other additives makes it the portland cement, Packing Plant and Material Handling equipment completes the offers.
Clinker Grinding Plant Requires Following Raw Materials : Clinker, Gypsum, Additives
The features of Cement Clinker Grinding plants: Economical, Less Power consumption, High Performance, Minimum Maintenance, Low cost of Production, Robust construction.
- Crushing and Storage
Clinker and Gypsum are carried from stock yards and dumps into a dump hopper. A Vibrating feeder controls feed rate. The Granulator which is feed by means of a belt conveyor Crushes, and then stores into the respective Silos/Hoppers by means of a Bucket elevator. The table feeder than feeds the crushed material in the desired proportion to the Ball Mill hopper.
- Cement Milling
The mix is intermediately stored to the Ball mill hopper by a Bucket Elevator. A mill feeder is installed to control the feed rate to mill, and adjust the desired fineness. The ball mill grinds the mixture which can now be called Portland cement. The Cement thus produced is stored into the Cement Silos. To ensure homogenized and consistent quality of cement, the same is blended through the aeration assemblies.
- Packing
The Screw Feeders extract and transport the Cement to the Packing Plant where a preliminary screening removes any foreign/unwanted particle and than stores it into a hopper where it is packed with the help of Auto Packaging plants.
