Home > Products > Cement Packing Machine > BHYW- 8 rotary cement packing machine
BHYW- 8 rotary cement packing machine
- 120 Set / Sets per Month
- Shanghai Tianjin
- T/T
You May Like
Product Details
| Condition | New | Production Capacity | 120TPD | |
| Place of Origin | Henan, China | Brand Name | Huanqiu heavy | |
| Model Number | cement packing machine | Voltage | 220V | |
| Power(W) | 15kw | Dimension(L*W*H) | 15000 | |
| Weight | 9.6T | Certification | CE AND ISO | |
| Warranty | one year |
Product Description
Specifications
BHYW- 8 rotary cement packer Rotary cement packing machine1.8 spouts packing machine
2.large capacity and automatic
rotary cement packer/ BHYW- 8/10D Rotary cement packing machinery
This series of products are mainly used for cement packing and also for the other powder and granular materials with good floating performance, during the packing process, except manually inserting bags on the discharging spouts, it can realize the work of filling up, weighing, falling down bags automatically and continuously.
This series have 3 types with different No. of spouts, 8 spouts,10 spouts, and 12 spouts. We can produce as per your requirement.
Functions:
- Filling cement, when inserting a bag;
- Bag will not fall down, when its weight doesn’t reach the set value;
- One bag falls off accidently; the flashboard will shut down immediately.
Features:
- Accurate weighing, lower energy consumption;
- Great packing capacity and easy maintenance;
- Realize functions of bag mouth pressing and releasing, opening and closing flashboards, falling bag down automatically without any pneumatic components, reduce a lot of troubles caused by pneumatic components damage.
No. | Description | Units | Data | No. | Description | Units | Data | |||
1 | Qty. of spout | Piece | 8 | 11 | Power fluctuations | % | +10 -15 | |||
2 | capacity | t/h | 120 | 12 | The main drive reducer | BLD3-59-2.2 | ||||
3 | Weighing Precision | Single bag weight | kg | 50 | 13 | The motor | model | Y100L1-4 | ||
Power | kW | 2.2 | ||||||||
95% single bag weight error | kg | +0.4 -0.2 | 14 | Discharging Motor | model | Y112M-4 | ||||
Power | kW | 4 | ||||||||
speed | r/min | 1440 | ||||||||
The total weight of 20 consecutive bags | kg | 1000-1004 | ||||||||
Protection level | IP44 | |||||||||
4 | Rotating tube diameter | mm | φ1520 | |||||||
5 | The outer diameter of spout | mm | φ2250 | 15 | power | kW | 4×8+2.2=34.2 | |||
6 | The distance from spout to the ground | mm | 1180 | 16 | The dust collecting airflow | m3/h | 10000 | |||
7 | The max.Turning diameter | mm | φ2500 | 17 | Pressure of dust collecting wind | Pa | -600 | |||
8 | The range of turning speed | r/min | 0~6 | 18 | The direction of turning | Overlooking | clockwise | |||
9 | The speed limit | r/min | 5 | 19 | Height | mm | 6430 | |||
10 | Power supply | AC 50Hz 3N 380V | 20 | Total weight | kg | 6000 | ||||
