Specifications
8 -spouts Automatic Cement Bag Packing Machineautomatic operation with microcomputer
great packing capacity
Introduction of 8 -spouts Automatic Cement Bag Packing Machine
It is mainly used for the automatic filling of the cement bag, because of its stable performance, few parts, simple maintenance, low cost,
economic durable,so it's favored by manufacturer.
This machine uses spiral gray dragon spitting instead of the traditional impeller lose ground , pushing out
gray ash fluently, more beneficial to the environment;
2, the vulnerability is few, need not pneumatic devices, greatly reducing equipment investment and
maintenance cost;
3, controlled by computer measurement, high sensitivity, fully comply with the national standard;
4, a high degree of automation, such as filling, measuring, off bag, etc, all be continuous completion.
5, the optimization design, simple structure, convenient maintenance, sealed tight, not plugging, not
jaming, not leak;
Features of 2014 hot sale rotary cement bag packer in cement packing line:
2.Except bag inserting manually ,all of above operations can be continuously ,automatically completed ,such as filling ,measuring ,bag falling down etc,
3.special functions :
4.more advantages such as rational structrue ,accurate measurement ,,low energy consumption, greater packing capacity, convenient maintenance etc.
5.most outstanding feature is:
6.The series packer is equipped with microcomputer balance which is designed by our technical team considering the structure of rotary packer and cement material packing characteristic and it has high accurate measurement and good stability.
Technical Parameter of 8 -spouts rotary cement bag packing machine for cement plant :
No. |
Description |
Units |
Data |
No. |
Description |
Units |
Data |
|||
1 |
Qty. of spout |
Piece |
8 |
11 |
Power fluctuations |
% |
+10 -15 |
|||
2 |
capacity |
t/h |
120 |
12 |
The main drive reducer |
BLD3-59-2.2 |
||||
3 |
Weighing Precision |
Single bag weight |
kg |
50 |
13 |
The motor |
model |
Y100L1-4 |
||
Power |
kW |
2.2 |
||||||||
95% single bag weight error |
kg |
+0.4 -0.2 |
14 |
Discharging Motor |
model |
Y112M-4 |
||||
Power |
kW |
4 |
||||||||
speed |
r/min |
1440 |
||||||||
The total weight of 20 consecutive bags |
kg |
1000-1004 |
||||||||
Protection level |
IP44 |
|||||||||
4 |
Rotating tube diameter |
mm |
φ1520 |
|||||||
5 |
The outer diameter of spout |
mm |
φ2250 |
15 |
power |
kW |
4×8+2.2=34.2 |
|||
6 |
The distance from spout to the ground |
mm |
1180 |
16 |
The dust collecting airflow |
m3/h |
10000 |
|||
7 |
The max.Turning diameter |
mm |
φ2500 |
17 |
Pressure of dust collecting wind |
Pa |
-600 |
|||
8 |
The range of turning speed |
r/min |
0~6 |
18 |
The direction of turning |
Overlooking |
clockwise |
|||
9 |
The speed limit |
r/min |
5 |
19 |
Height |
mm |
6430 |
|||
10 |
Power supply |
AC 50Hz 3N 380V |
20 |
Total weight |
kg |
6000 |
||||
