Specifications
PL1600 Batching MachineISO9001:2000; ISO14001
Reliable performance
High quality with conpetitive price
Hot sale
PL1600 batching machine
As a matching and auto dispensing equipment for Js series concrete mixer , the PL series batching machine can complete the batching program for sandstone material according to customer requirements. In addition, this machine consists of storage hopper ,weighing system, feeder system ,electric control system and so on. There are two kinds of feeding ways like pneumatic brake and belt convey.
PL1600 batching machine is a kind of modified concrete batching equipment and used to prepare concrete mixture. It can prepare three kinds of material, adopts electronic scale measuring, automatic batching program control, six-door design. It is of higher batching accuracy, higher speed, strong applicability; easy to operate and reliable to use. The mixture ratio can be regulated freely, simple and intuitive.
Model: PL1600 Batching Machine | |||
Sandstone bucket volume m³ |
3*12 |
Belt conveyor power KW |
2*4 |
Batching period S |
≤ 60 |
Weighing hopper volume m³ |
2.4 |
Measuring accuracy % |
±2 |
Measuring mode |
Electronic scale |
Overall size (length*width*height) mm |
10,180×2,305×2,900 |
||
Machine weight kg |
5,000 |
||
Lubricating part |
Season |
Lubricant category |
Oil volume |
Motorized pulley of belt conveyer |
Summer (25) |
120# Industrial gear oil |
Not below 20mm. |
Spring and autumn (10-25) |
90# Industrial gear oil |
||
Winter (-5-10) |
70# Industrial gear oil |
||
Air compressor |
Summer |
19# Industrial gear oil |
Add oil to upper limit of oil level. Add oil in time as the oil level descends. |
Winter |
13# Industrial gear oil |
||
Air source triplet |
HU-30(GB2537) antirust steam turbine oil |
The oil should not exceed max oil level; add oil in time as the oil is near min oil level. |
Batching machine:
Certificates:
Our factory :
our customer:
Welcome come to our factory.
