HLS90 Concrete Mixing Station

HLS90 Concrete Mixing Station thumbnail-1
HLS90 Concrete Mixing Station photo-1
US$ 10,000 - 500,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Power Type:
Electric
Place of Origin:
Shandong, China
Contact Supplier Request Quote Chat Now
Shandong Lianchuang Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Power Type Electric
Place of Origin Shandong, China
Brand Name Lianchuang
Model Number HLS90
Power(W) 230kw
Weight 4500kg
Certification ISO:9001
Warranty 1year
After-sales Service Provided Overseas service center available

Specifications

Concrete mixing plant's main advantages are as follows:1.High standard environmental protection.2.Superior Mixing Performance.

 HZS Series of  Concrete Batching Plant

HZS25,HZS40,HZS50,HZS75,HLS60,HLS90,HLS120,HLS180,HLS240.



 1. Adopting twin forced horizontal shafts stirrer

 2. The aggregate is measured alone or accumulated by the electronic scale

 3. Water and the additive are measured accurately under the centralized control of

the computer

 4. The whole machine adopts PC to control, which is easy to operate and debug

 5.  Model for feeding aggregate: belt transfer

 6. The main electric elements are the devices of Schneider in France; the programmable controller is the product of well-known brand.



 Main technical parameter:

Model

HLS60

HLS90

HLS120

HLS180

HLS240

Production rate   m3/h

60

90

120

180

200

Matching stirring mill

JS1000

JS1500

JS2000

JS3000

JS4000

Storage bin capacity m3

3×15/4×15

3×15/4×15

4×20

4×30

4×30

Discharging height m

3.8

3.8

3.8

3.8

3.8

Total power kW

141

195

230

265

326

Aggregate measuring accuracy %

±2

±2

±2

±2

±2

Cement measuring accuracy %

±1

±1

±1

±1

±1

Water measuring accuracy %

±1

±1

±1

±1

±1

Fly ash measuring accuracy %

±1

±1

±1

±1

±1

Additive measuring accuracy %

±1

±1

±1

±1

±1

Total weight Kg

30000

45000

70000

80000

90000



Features:

1)Batcher

2)Trough Belt conveyor

3)Mixer JS500,JS750,JS1000,JS1500 ,JS2000,JS3000,JS4000

4)Weighing system

5)Mixing platform

6)Control system

7)Pneumatic system

8)Cement silos

9)Screw conveyor





Concrete Batching plant of HZS25,40,50,75;

Concrete batching station:HLS60,90,120,180,240;



Welcome to your inquiry!







Welcome to visit our factory!







Alibrothers construction machinery is your best choice!







2012Super Quality Mobile Ready Mix Concrete Plant, 2012Super Quality Mobile Ready Mix Concrete Plant products, Mobile







Customers around the world :



HLS90 Concrete Mixing station





High quality !



HLS90 Concrete Mixing station



  HLS90 Concrete Mixing station

We are selection of High-quality steel :







High quality Concrete mixer:





Batching plants:



HLS90 Concrete Mixing station







Cement silo:







Control Room:



HLS90 Concrete Mixing station





High-quality parts:





HLS90 Concrete Mixing station



Control system :



Project Case :

HLS90 Concrete Mixing stationHLS90 Concrete Mixing station







IF you are interesting, Please let me know:



    Please contact me:





  HLS90 Concrete Mixing station
