Specifications
cement silo:1.Piece of cement silo.
2.Silo Operated easily.
3.long life time
Welcome to your inquiry!
Welcome to visit our factory!
Alibrothers construction machinery is your best choice!
Cement silo is a concrete mixing station of supporting products, mainly has the following characteristics:
1. Put in bulk powder (cement or fly ash), waterproof and moisture, easy to use and reduce costs
2.the top of cement silo with green filter, used to reduce dust leakage. Equipped with a safety valve at the top of cement silo, cement silo used to balance the pressure difference between inside and outside. Upper and lower parts of the cement silo is equipped with display materials, can monitor the number of cement materials warehouse. With gas in the lower part of broken cement storage devices, to ensure smooth unloading.
3. Cement bin is cylinder and supporting structure. The superior part has dust removing device to avoid leakage of dust; and the inferior part is equipped with arch breaker to avoid powder caking and make discharging smooth, and bin level sensing device to master usage of material in the bin at any time.
4 Cement bin generally adopts bulk cement conveying truck to send powder in the bin by pneumatic conveying; according different structures of cement bin, there are two kinds of discharging: the first is the inferior part is connected with screw conveyer and screw conveyer send powders into powder measure; the second is to adopt pneumatic conveying (to special cement bin).
|
Model |
Dia. x Height |
Discharge height |
Thickness |
Weight |
50T |
3.14m x 15.5m |
3.9m |
3.4.5(mm) |
5200kg |
100T |
3.14m x 17.9m |
3.9m |
3.4.5(mm) |
8500kg |
150T |
3.14m x 21.8m |
3.9m |
4.5.6(mm) |
12000kg |
200T |
4.5m x 17.9m |
3.9m |
4.5.6(mm) |
15000kg |
300T |
5.2m x 17.9m |
3.9m |
5.6(mm) |
19000kg |
tCustomers around the world
i statio
nc
High quality !
Please contact me:
rete mixing plant---cement silo.
