Specifications
Bulk Cement TruckThe compact hydraulic unit drives, High capacity water tank, Ecological cover (optional)
Bulk Cement Truck
Model:7m3 concrete truck mixer, 8m3 concrete truck mixer, 9m3 concrete truck mixer, 10m3 concrete truck mixer 12m3 concrete truck mixer
Specification:
Drum: Geometric volume (m3 ) :12.5-20.5
Effective agitate volume (m3) :7-12
Rotational velocity (r/min) 0~14 for all models
Rotation direction (from the rear of truck):Charge in clockwise, discharge in anticlockwise
Vane: Double-screw vane
Charge and discharge device:
Hopper (L×W) (mm):950×1000
main hopper length (mm):1600
The annex hopper length (mm):780
Water supply system: water pump (WP24-180B12) or (WP24-180B12)
Drum made by special anti-wear steel St-52 and 3990-type manganese steel
Minimum drum secretion due to special assembly apparatus
Fully sandblasted steel parts with double primer coating and final painting in heated paint oven
The compact hydraulic unit drives
High capacity water tank
Ecological cover (optional)
8m3 concrete truck mixer
Geometric volume: 13.8m3
Efficitive agitate volume: 8m3,
Effictive mixing volume: 6m3
Inclination angle: 15
Vane: Double-screw vane
Oil pump: A4VTG71
Motor: PLM7
Type of engine/Power: WD615.69/247 WD615.87/213
9m3concrete truck mixer
Geometric volume: 16.5m3
Efficitive agitate volume: 9m3,
Effictive mixing volume: 7.5m3
Inclination angle: 12
Vane: Double-screw vane
Oil pump: A4VTG71
Motor: PLM7
Type of engine/Power: WD615.69/247kW
10M3 Concrete truck mixer
Chassis: DFL5251GJBA1 Dongfeng Automobile Group
Engine: dCi340-30 Dongfeng
Brake: Steam Brake
Speed Gearbox: 8JS130T-B
Cab Corp Cab: Dongfeng
Rear Axle: 13T
Spring Leaf No: 9/13
Tire & Spare Tire: 11.00R20
Reducer 577L: Italy
Hydraulic pump: 54 USA
Hydraulic motor:54 USA
Cooler: 54 Liters China
Capacity of Tank (m3): 8 or 10
Material of Tank: 16 Manganese Steel
Thickness of Tank (mm): 5
Kerb Weight / Payload Weight / Gross Weight: 12825 / 12000 / 24955
Overall Dimension (mm): 9800 x 500 x 960
Wheelbase (mm): 3800 + 1350
