CS3185 composting turner fertilizer trough turning machine for oganic waste
Introduction Trough Turner
The trough turner is suitable for aerobic compost. It can work together with solar compost house,
compost tunnel and transfer carriage.
Together with transfer carriage, the turner can move from one tunnel to others.Working on tunnel,
turner can achieve continual or batch discharge.
Applications
Trough turner equipment is mainly for manure, sludge waste, sugar mill filter mud, bad meal and
straw residue sawdust and other organic waste fermentation turning, widely used in organic
fertilizer plants, fertilizer plants, sludge dumps , horticulture plantation and other fields, and white
button mushrooms and remove moisture
fermentation composting operations.
CS3815 Parameters of Trough Turner
Max material width in vessel: 19m
Max material height in vessel: 1.5m
Turning width each time: 3.8m
Turning cross sectional area each time: 5.7m2
Max granule diameter for the compost: 250mm
Working portrait turning distance: 2~3m
Max capacity: 600~700/hr
Walking speed: 0~1.5m/min
Retreat speed: 0~5m/min
Height difference for the vessel floor: 10~ 30mm
Vessel wall height: 1800mm
Vessel wall width: 300mm
Track center distance: 19300mm
Width for the turning machine: 19600mm
Height for the turning machine: about 3200mm
Weight for the turning machine: about 8000kg
Installing total tower: 142.7KW
Turning machine tower: 132KW
Radiator power: 2.2KW
Cable reel plate power:3KW
Walking power: 5.5KW
Equipment hydraulic parts brand: imported
electric appliance brand: CHINT
PLC:Delta
Remote control unit: Taiwan
Allocation and parameter
Corporate Profile
FDSP is specialized in manufacturing feed machinery, fertilizer machinery, biomass machinery and
turn-key project. We have dedicated for R&D of organic compound fertilizer for many years and we
can undertake turn-key project with capacity 10,000-100,000 tons per year. It can be produced for
Organic fertilizer, such as manure of CHICKEN, SWINE, CATTLE and Waste of grains, Sewage &
organic waste after stacking, fermentation, and granulation. We can customize and design turn-key
project for all kinds of material for customers according to their various request, materials, and site.
Turn- key Project
FDSP has sold fertilizer machinery,feed machinery and biomass machinery throughout China and
exported to Korea, South Africa,Russia, Thailand, Philippines, Malaysia, Australia, Egypt, Syria,
Nigeria, Ethiopia, India, Bangladesh, Pakistan, Iran etc. A complete set of
fertilizer production line with capacity of 10tph was exported to South Korea in 2008;a complete set
of pulverized coal pellet production line with capacity of 30t/h was
exported to South Africa in 2009.Three complete sets of feed production lines were
export to Egypt with capacity of 10tph, 15tph and 20tph respectively from 2010 to
2012. A large model of pellet mill with capacity of 25tph was export to Thailand in 2013.
Our customers from all over the world
1. Answer all your questions by our experienced staffs in professional and fluent English.
2. Exclusive and unique solution can be offered to our customers by our well trained and professional engineers.
3. Factory lowest price
4. Do the best fertilizer machine in China
1. Q:Are you a factory or trading company?
A: We are a manufacturing and trading company.
2. Q:Where is your factory located? How can I visit there?
A: Our factory is located in Liyang City, Jiangsu Province, China, near Shanghai. Our company is located in Nanjing City, Jiangsu Province, China.You can fly to Shanghai airport directly. All our clients, from home or abroad, are warmly welcome to visit us!
3. Q:How does your factory do regarding quality control?
A:"Quality is our soul. We always attach great importance to quality controlling from
the beginning to the end. We have many engineers to R&D our products.
Why choose us?
- We have 13 years' manufacturing experience in fertilizer machinery.
- We have exported our products to more than 30 countries all over the world.
- All of our machines are built in with the most advanced technology.
- Our R&D team have rich experience in researching, designing, testing and installing machines.
- Our sales team provide 24 hours online or email service.
Our products have passed CE certification long before, also the pellets is with SGS certification.
Our company is with ISO9001 certification.
Besides,we have a professional technical team,with two departments for developing single machineand customizing complete pellet line solution. Most of our engineers are with over 20 years'
experience in this field and also have a lot of experience in overseas projects.
With our outstanding technical team, we have earned a lot of certifications for our machines,
together with a lot of patented design.
