Specifications
Concrete batching plant machine1.Quick disassembling
2.With good performance
3.Capacity:35m3/h
4.Low noise
NEW YHZS35 Concrete batching plant machine
1. Introduction of YHZS35 Concrete batching plant machine
Superior machine issued by industrial PC computer as host, have the ability of strong anti-interference , and reliable operation; Centralized monitoring, VGA high-definition sc-reens, Chinese menu prompts, intuitive and clear, easy to learn and easy to operate; Input and modify parameters online, print data; Power-fail protection function with data, a power outage or shutdown, data is not lost, permanent preservation, after startup without having to input data.
2. Parameters of mobile Concrete batching plant machine
Model |
YHZS25 |
YHZS35 |
YHZS50 |
|
Production(m3/h) |
25 |
35 |
50 |
|
Mixer |
|
JS500 |
JS750 |
JS1000 |
power(kw) |
18.5 |
30 |
2×18.5 |
|
output(m3) |
0.5 |
0.75 |
1 |
|
grain size(mm) |
40 |
40 |
60 |
|
Batcher |
hopper capacity(m3) |
15 |
21 |
39 |
hopper quantity (pcs) |
3 |
3 |
3 |
|
Conveyor Capacity(T/h) |
100 |
150 |
200 |
|
Weighting Scope Accuracy |
aggregate(kg) |
1300±2% |
2000±2% |
2500±2% |
cement(kg) |
400±1% |
500±1% |
600±1% |
|
adulterant(kg) |
|
150±1% |
200±1% |
|
water(kg) |
200±1% |
250±1% |
300±1% |
|
admixture(kg) |
150±1% |
35±1% |
35±1% |
|
Total power(kw) |
≈47 |
≈70 |
≈82 |
|
Discharge height(m) |
3.8 |
3.8 |
3.8 |
|
3. Constituent part of mobile Concrete batching plant machine
JS750 concrete mixer
PLD1200 batching machine
Cement silo
Control system
Weighing system
1.Delivery time: 15 days after receipt of your deposit.
2.Payment terms: 30% T/T in advance, the balance is paid (by T/T) before delivery.
3.Package:
1).Wire cables are used for fastening the machine on the trailer or inside the container.
2).Cork wood are placed in front or behind the machine to protect it.
3).Plastic film is covered on the machine as a rain-roof.
4).Crane is used during the whole loading.
Why chose Henan Teng Fei-mobile concrete batching plant price?
1.Teng Fei give priority to with construction company, during years of construction equipment, progress in practice and has strong practicability.
2.Our company has years of experience in project negotiation and can provide customers with effective business negotiations guidance to win project
3.in addition to providing equipment and technical training, we also provide free foam concrete project system solutions to help you get maximum benefit.
How long is the warranty-mobile concrete batching plant price?
The warranty period is 12 months.
What services does it provide-mobile concrete batching plant price?
1.pre-sale service: our company can provide technological guidance and formulate suitable equipment matching program according with your specific production requirements.
2.on-purchase service: our company can solve professional technical problems and other related issues for you.
3.after-sales service: our company provides that engineers available to service machinery overseas and equipment for life maintenance.
What is the Teng Fei’s basic philosophy-mobile concrete batching plant price?
Henan Teng Fei Machine Manufacturing Co., Ltd. is a collection of scientific research, development, production marketing for the integration of manufacturing enterprise; The company execute principles “development is a competition philosophy” and take “efficient, pragmatic, cooperation, innovation “as beliefs.
