Specifications
YZS25 Concrete mixer portable1.Cycle length:72s
2.BV
3.Capacity:25 CBM/h
4.Discharging height:1.7-3.8m
1. Introductions of YHZS25 Concrete mixer portable
YHZS25 mobile concrete batching plant for sale with advanced technology in the world has various operational modes as fully automatic, semi-automatic and manual and so on. adopt double shafts mixer JS500 as main machine, and PL1800 batching device as dosing mechanism, SNC50A cement silo and LSJ20F screw conveyor as storage and conveying mechanism.
2. Advantages of YHZS25 Concrete mixer portable
| 1) The main electrical components are from the Schneider Electric Company |
| 2) Measure system. YHZS25 mobile concrete batching plant for sale equips with electronic scales to measure. |
| 3) Microcomputer control system. The microcomputer control system of YHZS25 mobile concrete batching plant for sale provides the functions of screen display, automatically equalize the fall and distributing ratio storage, and also can manage, store and print data. |
| 4) Environmental protection. YHZS25 mobile concrete batching plant for sale equipe with the dust collective device. |
| 5) Low cost, easy mobile and small occupation area; It can be manually controlled or automatic control. |
3. Technical parameters of YHZS25 Concrete mixer portable
|
Model |
YHZS25 |
The whole plant part |
Capacity (m³/h) |
25 |
Discharging height (m) |
1.7-3.8 |
|
Cycle length (s) |
72 |
|
Dimension (mm) |
17843*11430*13000 |
|
Install gross capacity (m³/h) |
50.25 |
|
Mixing part |
Model |
JS500 |
Batching part |
Model |
PLD1200 |
Air circuit system |
Air compressor mold |
WA-100 |
Rated discharging pressure (mpa) |
0.7 |
|
Air displacement (m³/min) |
0.71 |
|
Motor capacity (kw) |
5.5 |
|
Weighing system |
Sand weighing precision |
2% |
Cement weighing precision |
1% |
|
Water weighing precision |
1% |
4. Constituent part
1. JS500 concrete mixer
2. PLD1200 cocnrete batching plant
3. Cement silo
1.Delivery time: 15 days after receipt of your deposit.
2.Payment terms: 30% T/T in advance, the left is paid (by T/T) before delivery.
3.Package:
1).Wire cables are used for fastening the machine on the trailer or inside the container.
2).Cork wood are placed in front or behind the machine to protect it.
3).Plastic film is covered on the machine as a rain-roof.
4).Crane is used during the whole
Why chose Henan Teng Fei? Concrete mixer portable
1.Teng Fei give priority to with construction company, during years of construction equipment, progress in practice and has strong practicability.
2.Our company has years of experience in project negotiation and can provide customers with effective business negotiations guidance to win project
3.in addition to providing equipment and technical training, we also provide free foam concrete project system solutions to help you get maximum benefit.
How long is the warranty? Concrete mixer portable
The warranty period is 12 months.
What services does it provide?
1.pre-sale service: our company can provide technological guidance and formulate suitable equipment matching program according with your specific production requirements.
2.on-purchase service: our company can solve professional technical problems and other related issues for you.
3.after-sales service: our company provides that engineers available to service machinery overseas and equipment for life maintenance.
What is the Teng Fei’s basic philosophy?
Henan Teng Fei Machine Manufacturing Co., Ltd. is a collection of scientific research, development, production marketing for the integration of manufacturing enterprise; The company execute principles “development is a competition philosophy” and take “efficient, pragmatic, cooperation, innovation “as beliefs.
Henan Teng Fei Machine Manufacturing Co., Ltd. is a collection of scientific research, development, production marketing for the integration of manufacturing enterprise; The company execute principles “development is a competition philosophy” and take “efficient, pragmatic, cooperation, innovation “as beliefs.
Teng Fei Group is a manufacturer of construction machine and mine machine, with more than 15 years experience, mainly produce concrete batching plant, AAC block line, stabilized soil mixing plant, dry mortar production line, cement production line, concrete mixer, concrete pump ,concrete truck, cement silo, crusher, ball mill, raymond mill, sand making line and so on.
