Help CenterNEW Aggregate Batcher PLD1200 Concrete Batching Machine
Related Products
-
NEW Pld600 Small Mobile Concrete Batching Machine PLD600 for SaleUS$ 2,056 - 3,650MOQ: 1 Set -
NEW Pld 1600 Aggregate Concrete Batching Hopper MachineUS$ 3,956 - 5,650MOQ: 1 Set
-
Factory Direct- Pld 800 Concrete Batching Machine PLD800US$ 2,056 - 3,650MOQ: 1 Set
-
TOP SELLING-pld600 Small Mobile Concrete Batching MachineUS$ 2,056 - 3,650MOQ: 1 Set
-
NEW Pld 1200 Batching Machine / PLD1200 Concrete BatchingUS$ 5,682 - 6,858MOQ: 1 Set
Specifications
PLD1200 aggregate batcher1.Out volume:4*3m3
2.Productivity:60
3.Weighing hopper capacity:800L
4.BV
Concrete batching machine loading materials by loader or belt conveyor is automation equipment used for quantitative distribution of materials, which mainly used in concrete construction industry to replace artificial platform scale or volume measurement, etc .
Application of PLD1200 aggregate batcher
PLD series concrete batching machine is a kind of equipment with automatically batching material on the front desk and using mixer together. It can automatically finishing the batching procedures of 3-6 kinds of materials (second grade concrete) such as sand, stone, cement according to users’ requirement. These serial products adopt electronic weighing, computer control, digital display, wired remote control operation, and have such advantages as accurate weighing, high precision batching, quick speed, strong control function and convenient operation. After this serial concrete batching machine with relative concrete mixer, different types and specification combined concrete mixing station can be formed.
Parameters of PLD1200 aggregate batcher
Type |
PLD800 |
PLD1200A |
PLD1200B |
Weighing Hopper Capacity |
800 |
1200 |
1200 |
Storing Hopper Capacity |
3*2m3 |
4*3m3 |
3*3m3 |
Productivity(m3/h) |
48 |
60 |
60 |
Batching Accuracy |
±2% |
±2% |
±2% |
Max measuring(kg) |
2000 |
3000 |
3000 |
Aggregate |
2—3 |
2—4 |
2—4 |
Feeding Height(mm) |
2430 |
2600 |
2600 |
Speed of feeding(m/s) |
1.25 |
1.25 |
1.25 |
Power(kw) |
3*3 |
3*3 |
4*3 |
Total weight |
2300 |
2800 |
410 |
Outline dimension |
5400 |
6000 |
8400 |
1.Delivery time: 15 days after receipt of your deposit.
2.Payment terms: 30% T/T in advance, the balance is paid (by T/T) before delivery.
3.Package:
1).Wire cables are used for fastening the machine on the trailer or inside the container.
2).Cork wood are placed in front or behind the machine to protect it.
3).Plastic film is covered on the machine as a rain-roof.
4).Crane is used during the whole loading.
Why chose Henan Teng Fei?
1.Teng Fei give priority to with construction company, during years of construction equipment, progress in practice and has strong practicability.
2.Our company has years of experience in project negotiation and can provide customers with effective business negotiations guidance to win project
3.in addition to providing equipment and technical training, we also provide free foam concrete project system solutions to help you get maximum benefit.
How long is the warranty?
The warranty period is 12 months.
What services does it provide?
1.pre-sale service: our company can provide technological guidance and formulate suitable equipment matching program according with your specific production requirements.
2.on-purchase service: our company can solve professional technical problems and other related issues for you.
3.after-sales service: our company provides that engineers available to service machinery overseas and equipment for life maintenance.
What is the Teng Fei’s basic philosophy?
Henan Teng Fei Machine Manufacturing Co., Ltd. is a collection of scientific research, development, production marketing for the integration of manufacturing enterprise; The company execute principles “development is a competition philosophy” and take “efficient, pragmatic, cooperation, innovation “as beliefs.
Henan Teng Fei Machine Manufacturing Co., Ltd. is a collection of scientific research, development, production marketing for the integration of manufacturing enterprise; The company execute principles “development is a competition philosophy” and take “efficient, pragmatic, cooperation, innovation “as beliefs.
Teng Fei Group is a manufacturer of construction machine and mine machine, with more than 15 years experience, mainly produce concrete batching plant, AAC block line, stabilized soil mixing plant, dry mortar production line, cement production line, concrete mixer, concrete pump ,concrete truck, cement silo, crusher, ball mill, raymond mill, sand making line and so on.
