Easy Transport Beton Mixing Machine, Yhzs35 Mobile Concrete Batching Plant
- 20 Set / Sets per Month
- Chinese main port
- T/T
- hzs180 giant concrete batching plant complete concrete mixer plant on market
- complete set hzs180 big size concrete batching plant used for construction
- competitive price hzs180 concrete batching plant with sicoma mixer
- high performance 180m3/h capacity concrete batching plant with conveyor belt
- competitive low factory price concrete mixing batching plant for sale
- commercial concrete batching plant hzs120 mixing plant stationary for hot sale
Product Details
Condition: | New | Power Type: | Electric | Place of Origin: | Henan, China |
Brand Name: | FOCUS | Model Number: | YHZS35 | Power(W): | 60kw |
Dimension(L*W*H): | 18mx4mx8.2m | Weight: | 45t(optional parts not included) | Certification: | ISO9001:2008 |
Warranty: | 12 Months | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Easy Transport Beton Mixing Machine, Yhzs35 Mobile Concrete Batching Plant
Installation Video of Mobile Concrete Batching Plant:
/channel/UCew-L-l5cXqYflSxgFOjTlg
Excellent Mixing Performance:
1. Horizontal twin-shaft compulsory mixer has the strong mixing ability with uniform mixing and high production output. The admixtures are widely mixed by the shafts, and reach the best proportional ratio of uniform;
2. The mixing shafts adapt anti-binding technology to prevent the cement from binding on the shafts;
3. Mixing paddles, arms and blades are made of special high chromium and high manganese alloy materials. The wear resistance of the mixing paddles saves time and cost to replace, and at the same time, improves the machines durability and reliability
4. The greasing system, which is controlled by central control system, lubricates the greasing points at the fixed position, fixed time and fixed quantity.
5. Decelerating system uses high-speed, synchronized, and closed planetary decelerators. 6. The opening of discharge gate can be adjusted by hydraulic system as per specific requirements.
Sizes of Mobile Concrete Batching Plant:
YHZS25(25cbm/h) mini small mobile concrete batching plant,
YHZS35(35cbm/h) mini small mobile concrete batching plant,
YHZS50/60(50-60cbm/h) small mobile concrete batching plant,
YHZS75(75cbm/h) small mobile concrete batching plant
Why would our clients choose FOCUS mobile concrete batching plant?
1.FOCUS MACHINERY boasts an award-wining small mobile concrete batching plant product range with capacity from 25cbm to 75cbm hourly.
2.This series of small mobile concrete batching plant adopts semi-pulling structure with running system and equipped with standard coupling pin, hence can be dragged by a tractor at the maximum speed of 40km/h.
3.As uniquely and compactly designed it is, this small mobile concrete batching plant assembles whole functions of accurate material weighing, efficient aggregate conveying, homogeneous mixing, computer auto-controlling and trailing.
The mobile concrete batching plant is the ideal concrete plant for projects that require frequent removal from one site to another.
What are the main features of FOCUS mobile concrete batching plant?
1. Complete mobile unit:
Unit easily transported on-site as well as from project to project, on-board hydraulic system changes plant from travel mode to full operational within 2-3 hours for this small mobile concrete batching plant.
2. Reliability of mix consistency:
Computer and manual dual control mode can be converted easily by a simple switch, twin-shaft mixer offers this small mobile concrete batching plant a consistent high grade of evenly mixed material, with its good quality mixing blades, paddles, arms and liners.
3. Highly precise dosing of water, cement, fly-ash and additive
Focus small mobile concrete batching plant dosing is realized by three-point suspension sensors, and they are all metered separately.
4. Optimized and modular design
FOCUS mobile concrete batching plant is convenient either for container transport or for towing vehicles.
Demonstration with Photos:
FOCUS Mobile Concrete Batching Plant Technical Parameters:
Model | YHZS25 | YHZS35 | YHZS50/60 | YHZS75 | |
Output capacity | 25m³/h | 35m³/h | 50-60m³/h | 75m³/h | |
Overall power | 40kw | 60kw | 85kw | 105kw | |
Discharge height | 3800mm | ||||
Max. hauling speed | 40km/h | ||||
warranty | 13months after commissioning | ||||
After-sale service | Guidance on erecting, commissioning and operator training, 24/7 technical assistance afterwards | ||||
Concrete mixer | JS500 | JS750 | JS1000 | JS1500 | |
Motor power | 18.5kw | 30kw | 18.5kw×2 | 30kw×2 | |
Max. aggregate dia. | 80mm | ||||
Aggregate batcher | PLD800 | PLD1200 | PLD1600 | PLD2400 | |
Aggregate weighing precision | ±2% | ||||
Aggregate feeder | Belt conveyor | ||||
Other scale scope | Cement | ±1% | |||
water | ±1% | ||||
additive | ±1% | ||||
Control system | Auto computer control, 1 set | ||||
Pneumatic system | 1 set |
Each second you are paying visits to our webpage, our mobile concrete batching plants are being purchased, installed and operated all over the world:
Thanks for visiting, by the time you are paying attention to us, our mobile concrete batching plants are being delivered /distributed to the world everyday - it'll be such a great honor if you can join us.
