High Quality 50-60m3/H Mobile Concrete Batching Plant for Building Construction
∑YHZS series mobile concrete mixing station is a new mobile concrete my company to design the mixing station, mobile type at present domestic ideal mixing machine,modular design, compact and reasonable structure, completed a large part of function of mixing station in a trailer chassis; set aggregate, electronic weighing, ascension, stirringas one, a walk, a stop on the use, convenient moving, easy installation, is applicable to all kinds of pavement, bridge, dam, airport and other mobile site and building constructionproduction base.
∑The plant adopts a modularization design, and has overall advantages of compact structure, complete functions and comparatively low price.
∑The most important is that installation of whole plant can be completed within 3 days and discharging it possible within 2 days after commissioning. That mean the whole plant can be put into operation within 5days after being delivered.
Installation Video of Mobile Concrete Batching Plant:
/channel/UCew-L-l5cXqYflSxgFOjTlg
Why would our clients choose FOCUS mobile concrete batching plant?
1.FOCUS MACHINERY boasts an award-wining small mobile concrete batching plant product range with capacity from 25cbm to 75cbm hourly.
2.This series of small mobile concrete batching plant adopts semi-pulling structure with running system and equipped with standard coupling pin, hence can be dragged by a tractor at the maximum speed of 40km/h.
3.As uniquely and compactly designed it is, this small mobile concrete batching plant assembles whole functions of accurate material weighing, efficient aggregate conveying, homogeneous mixing, computer auto-controlling and trailing.
The mobile concrete batching plant is the ideal concrete plant for projects that require frequent removal from one site to another.
What are the main features of FOCUS mobile concrete batching plant?
1. Complete mobile unit:
Unit easily transported on-site as well as from project to project, on-board hydraulic system changes plant from travel mode to full operational within 2-3 hours for this small mobile concrete batching plant.
2. Reliability of mix consistency:
Computer and manual dual control mode can be converted easily by a simple switch, twin-shaft mixer offers this small mobile concrete batching plant a consistent high grade of evenly mixed material, with its good quality mixing blades, paddles, arms and liners.
3. Highly precise dosing of water, cement, fly-ash and additive
Focus small mobile concrete batching plant dosing is realized by three-point suspension sensors, and they are all metered separately.
4. Optimized and modular design
FOCUS mobile concrete batching plant is convenient either for container transport or for towing vehicles.
Demonstration with Photos:
FOCUS Mobile Concrete Batching Plant Technical Parameters:
| Model | YHZS25 | YHZS35 | YHZS50/60 | YHZS75 | |
| Output capacity | 25m³/h | 35m³/h | 50-60m³/h | 75m³/h | |
| Overall power | 40kw | 60kw | 85kw | 105kw | |
| Discharge height | 3800mm | ||||
| Max. hauling speed | 40km/h | ||||
| warranty | 13months after commissioning | ||||
| After-sale service | Guidance on erecting, commissioning and operator training, 24/7 technical assistance afterwards | ||||
| Concrete mixer | JS500 | JS750 | JS1000 | JS1500 | |
| Motor power | 18.5kw | 30kw | 18.5kw×2 | 30kw×2 | |
| Max. aggregate dia. | 80mm | ||||
| Aggregate batcher | PLD800 | PLD1200 | PLD1600 | PLD2400 | |
| Aggregate weighing precision | ±2% | ||||
| Aggregate feeder | Belt conveyor | ||||
| Other scale scope | Cement | ±1% | |||
| water | ±1% | ||||
| additive | ±1% | ||||
| Control system | Auto computer control, 1 set | ||||
| Pneumatic system | 1 set | ||||
