Specifications
concrete mixer truck with pump1.good pumping performance;
2.ISUZU Chassis,low oil consumption,great mobility;
3.ISO cer
Why would our clients choose FOCUS concrete mixer truck with pump?
- large pumping capacity with high efficiency;
- light-weighed and optimized design enables FOCUS concrete mixer truck with pump small occupation of ground area; used concrete mixer truck with pump
- low oil consumption, economic engineered; used concrete mixer truck with pump
-
full hydraulic system guarantee stable pumping performance.
Parameter of 48m/52m concrete mixer truck with pump
Parameter |
Unit |
HDT5380THB-48/5 |
HDT5420THB-52/5 |
Output in theory |
m3/h |
125 |
125 |
Bucket volume |
L |
700 |
700 |
Height of top surface of bucket |
mm |
1400 |
1400 |
Model of distribution valve |
|
S Valve |
S Valve |
Max. operation radius |
m |
43.7 |
47.8 |
Max. operation height |
m |
47.7 |
51.8 |
Max. operation depth |
m |
34.3 |
39.8 |
Open height of boom |
mm |
9065 |
9400 |
Distance between front landing legs |
mm |
9780 |
10295 |
Diameter of delivery pipe |
mm |
125 |
125 |
Quantity of boom |
|
5 |
5 |
Rotary angle of each boom |
° |
91/180/180/180/270 |
90/180/180/180/270 |
Wire line control distance |
m |
33 |
33 |
Remote control distance |
m |
200 |
200 |
Max. speed |
km/h |
89 |
80 |
Min. turn radius |
mm |
11900 |
12500 |
Brake distance |
m |
10 |
10 |
Chassis model |
|
ISUZU CYH51Y |
ISUZU CYH51Y |
Max. engine output power |
kw |
287(2200r/min) |
259(2100r/min) |
Max. engine output torque |
n.m |
1863(1100r/min) |
1460(1100r/min) |
Max, gradient ability |
% |
37 |
37 |
Fuel consumption |
L/100km |
38 |
38 |
Out dimension (L*W*H) |
mm |
13300*2500*4000 |
13990*2500*4000 |
Total weight |
kg |
38000 |
42000 |
Our concrete pumpings are being purchased, installed and operated all over the world:
Thanks for visiting, by the time you are paying attention to us, our concrete pumpings are being delivered /distributed to the world everyday - it’ll be such a great honor if you can join us:
For more information please visiting us @
