Specifications
Mini concrete mixer trucks :
1.FOTON 4x2
2.Imported hydraulic system and reducer
3.3m3, 4m3 capacity
Characteristics of 3m3, 4m3 6m3 Mini concrete mixer trucks
1.FOCUS 3m3, 4m3 6m3 Mini concrete mixer trucks ;
2.international famous brand hydraulic drive fits are adopted in our Mini concrete mixer trucks ;
3.integral type oil tank, oil cooler and electrical fan are adopted with simple and reliable system;
4.multi-points control system enables Mini concrete mixer trucks operation to be easier, safer and more comfortable;
5.air pressure water supply system with large capacity water tank.
What are the main features of FOCUS mini concrete mixer trucks ?
1.Oil tank and radiator are imported top brand combination with temperature control switch and vacuum meter while oil change and maintenance are easily realized for mortar mixer .
2.Pump, motor and reducer in FOCUS mini concrete mixer trucks are all original imported AMERICA static pressure driving system with big driving torque and high efficiency.
3.Imported hose and connector are separately from GERMANY EMB and ITALY MANULI.
4.Hose buckling device is totally from GERMANY HYDAC.
5.Stirring vat auto-welding improves mortar mixer production efficiency and makes welding quality finer.
6.Tri-axial design and three-section double logarithm helix surface design can ensure concrete speedy feeding and discharge and low surplus rate in our mini concrete mixer trucks
7.Fault indicator for mortar mixer can check all welding seams of stirring vat to ensure good welding quality after it’s being welded by auto-welding machine.
8.Truck frame adopts tri-axial lineation machining, and adopts laser check to ensure an accurate installation position.
FOCUS mini concrete mixer trucks technical parameters:
Model |
3m3 |
4m3 |
6m3 |
|
Tuck |
Chassis |
FOTON /HOWO |
FOTON /HOWO |
FOTON /HOWO |
Length(mm) |
6765 |
7705 |
8715 |
|
Width(mm) |
2499 |
2500 |
2496 |
|
Height(mm) |
3420 |
3700 |
3850 |
|
Weight(kg) |
15990 |
18570 |
25000 |
|
Load weight(kg) |
7805 |
9860 |
11770 |
|
Max.speed(kg/h) |
80 |
80 |
90 |
|
Engine |
Engine model |
YC4D130-33 |
YC6J190-33 |
WD615.69 |
|
Working device |
Drum volume(m³) |
5.05 |
6.15 |
8.7 |
Mixing volume(m³) |
3 |
4 |
6 |
|
Drum rotation(r/min) |
0-12 |
0-12 |
0-12 |
|
Discharge speed(m³/min) |
≥3 |
≥3 |
≥3 |
|
Surplus rate(%) |
<0.5 |
<0.5 |
<0.5 |
|
Water tank vol.(L) |
400 |
400 |
400 |
|
