Specifications
Concrete equipment
1.FOCUS4x4
2.Imported hydraulic system and reducer
3 . 8m3, 9m3,10m3, 12m3 ,14m3 capacity
Characteristics of 8m3, 9m3,10m3, 12m3 ,14m3 concrete mixer
1.FOCUS 8m3, 9m3,10m3, 12m3 ,14m3 HINO concrete mixer
2.international famous brand hydraulic drive fits are adopted in our concrete mixer ;
3.integral type oil tank, oil cooler and electrical fan are adopted with simple and reliable system;
4.multi-points control system enables concrete mixer operation to be easier, safer and more comfortable;
5.air pressure water supply system with large capacity water tank.
What are the main features of FOCUS concrete mixer ?
1.Oil tank and radiator are imported top brand combination with temperature control switch and vacuum meter while oil change and maintenance are easily realized for concrete mixer
2.Pump, motor and reducer in FOCUS concrete mixer all original imported AMERICA static pressure driving system with big driving torque and high efficiency.
3.Imported hose and connector are separately from GERMANY EMB and ITALY MANULI.
4.Hose buckling device is totally from GERMANY HYDAC.
5.Stirring vat auto-welding improves concrete mixer production efficiency and makes welding quality finer.
6.Tri-axial design and three-section double logarithm helix surface design can ensure concrete speedy feeding and discharge and low surplus rate in our concrete mixer
7.Fault indicator for mixing concrete can check all welding seams of stirring vat to ensure good welding quality after it’s being welded by auto-welding machine.
8.Truck frame adopts tri-axial lineation machining, and adopts laser check to ensure an accurate installation position.
| concrete truck mixer/concrete transit mixer/cement truck mixer/concrete mixing truck technical parameters: | ||||||
| Model | 8m³ | 9m³ | 10m³ | 12m³ | 14³ | |
| Tuck | Chassis | HINO | STEYR | HINO | HOWO | HOWO |
| Length(mm) | 8550 | 9200 | 9800 | 10150 | 10150 | |
| Width(mm) | 2490 | 2490 | 2495 | 2496 | 2496 | |
| Height(mm) | 3800 | 3800 | 3830 | 3900 | 3960 | |
| Weight(kg) | 25000 | 25000 | 31000 | 31000 | 31000 | |
| Load weight(kg) | 12600 | 13000 | 15650 | 16370 | 16700 | |
| Max.speed(kg/h) | 75 | 72 | 90 | 90 | 50 | |
| Oil consumption(L/100km) | 32 | 34 | 38 | 38 | 38 | |
| Engine | Engine model | WD615.69 | ||||
| Engine type | 6-cylinder direct injection diesel engine with water cooling | |||||
| Engine power(KW) | 247(2200r/min) | 247(2000r/min) | ||||
| Max.torque(N.M) | 1250(1600r/min) | |||||
| Working | Drum volume(m³) | 12.8 | 14.7 | 17.05 | 19.65 | 20.1 |
| device | Mixing volume(m³) | 8 | 9 | 10 | 12 | 14 |
| Drum rotation(r/min) | 0-14 | |||||
| Discharge speed(m³/min) | ≥3 | |||||
| Slump(m) | 100-230 | |||||
| Surplus rate(%) | <1 | |||||
| Water tank vol.(L) | 400 | |||||
Thanks for visiting, by the time you are paying attention to us, our concrete mixer truck are being delivered /distributed to the world everyday - it’ll be such a great honor if you can join us:
For more information please visiting us @
