Why would our clients choose FOCUS mobile concrete truck mixer?
- HINO chassis are available in FOCUS mobile concrete truck mixer;
- international famous brand hydraulic drive fits are adopted in our mobile concrete truck mixer;
- integral type oil tank, oil cooler and electrical fan are adopted with simple and reliable system; mobile concrete truck mixer
- multi-points control system enables the beton truck operation to be easier, safer and more comfortable; mobile concrete truck mixer
- air pressure water supply system with large capacity water tank.
What are the main features of FOCUS mobile concrete truck mixer?
- Oil tank and radiator are imported top brand combination with temperature control switch and vacuum meter while oil change and maintenance are easily realized for our mobile concrete truck mixer.
- Pump, motor and reducer in mobile concrete truck mixer are all original imported AMERICA static pressure driving system with big driving torque and high efficiency. mobile concrete truck mixer
- Imported hose and connector are separately from GERMANY EMB and ITALY MANULI. mobile concrete truck mixer
- Hose buckling device is totally from GERMANY HYDAC.
- Stirring vat auto-welding improves mobile concrete truck mixer production efficiency and makes welding quality finer.
- Tri-axial design and three-section double logarithm helix surface design can ensure concrete speedy feeding and discharge and low surplus rate in our mobile concrete truck mixer.
- Fault indicator for the mobile concrete truck mixer can check all welding seams of stirring vat to ensure good welding quality after it’s being welded by auto-welding machine. mobile concrete truck mixer
- Truck frame adopts tri-axial lineation machining, and adopts laser check to ensure an accurate installation position. mobile concrete truck mixer
FOCUS concrete mixer truck technical data
Model | 8m³ | 9m³ | 10m³ | 12m³ | 14³ | |
Truck | Chassis | HINO | HINO | HINO | HOWO | HOWO |
Length(mm) | 8550 | 9200 | 9800 | 10150 | 10150 | |
Width(mm) | 2490 | 2490 | 2495 | 2496 | 2496 | |
Height(mm) | 3800 | 3800 | 3830 | 3900 | 3960 | |
Weight(kg) | 25000 | 25000 | 31000 | 31000 | 31000 | |
Load weight(kg) | 12600 | 13000 | 15650 | 16370 | 16700 | |
Max.speed(kg/h) | 75 | 72 | 90 | 90 | 50 | |
Oil consumption(L/100km) | 32 | 34 | 38 | 38 | 38 | |
Engine | Engine model | WD615.69 | ||||
Engine type | 6-cylinder direct injection diesel engine with water cooling | |||||
Engine power(kg) | 247(2200r/min) | 247(2000r/min) | ||||
Max.torque(N.M) | 1250(1600r/min) | |||||
Working device | Drum volume(m³) | 12.8 | 14.7 | 17.05 | 19.65 | 20.1 |
Mixing volume(m³) | 8 | 9 | 10 | 12 | 14 | |
