Specifications
JZC electric small concrete mixer
1.Electric:JZC250, JZC350, JZC500, JZM750
2.Diesel:JZC250, JZC350
3.Portable, easy operated.
Why would our clients choose FOCUS JZC electric small concrete mixer?
FOCUS JZC series electric small concrete mixer is a kind of electric small concrete mixer, which can mix semi-rigid and plastic concrete.
The mixing drum is gear-driven and has characteristics of balance running, simple operation and high mixing quality. FOCUS JZC electric small concrete mixer can be composed as a medium-sized mixing station matched with feeding and weighing equipments, widely used in different kinds of construction projects, applicable in general construction sites, roads, bridges and hydropower projects, especially for urban residential construction. electric small concrete mixer
|
Model parameter |
JZC350 |
JZC500 |
JZC750 |
Discharge vol. |
350L |
500L |
1200L |
Charging vol. |
560L |
800L |
750L |
Output capacity |
10-14.5m³/h |
18-20 m³/h |
25-30 m³/h |
Aggregate dia. |
60mm |
60mm |
70mm |
Rotating speed |
14r/min |
13r/min |
13r/min |
Max. drag speed |
20km/h |
20km/h |
20km/h |
Mixing motor |
5.5kw |
7.5kw |
12kw |
Lifting motor |
4.5kw |
5.5kw |
7.5kw |
Pump motor |
0.55kw |
0.75kw |
0.75kw |
Weight |
1950kg |
3100kg |
3300kg |
|
Dimension L*W*H (mm) |
2766*2140*3000 |
5230*2300*5450 |
6200*2465*5450 |
Our equipments are being purchased, installed and operated all over the world:
Thanks for visiting, by the time you are paying attention to us, our JZC concrete mixers are being delivered /distributed to the world everyday - it’ll be such a great honor if you can join us:
