High performance, New JDY500 mini portable concrete mixer for sale,cement mixing machine

Specifications

High performance, New JDY500 mini portable concrete mixer for sale
1.energy efficient .
2.easy operation and maintenance

High performance, New JDY500 mini portable concrete mixer for sale,cement mixing machine





Description of JD series concrete mixer:

This series mixer can mix various matching of concrete, sand pulp, slurry, and apply to all kinds of medium and small-sized buildings. It is the ideal mixing equipment of concrete for user. It not only can use as a single machine, also can use with ingredient machine for a simple concrete mixing plant.



This series of JDY concrete mixer are single horizontal shaft mixer that integrates with mechanical, hydraulic and electrical. The mixing system depends on the cylindrical gear to rotate. It works reliably. The feeding part adopts the lifting electric machine. The discharging part adopts dual-role hydraulic cylinder to mix, thereby make this process fast and clean. The hydraulic system is controlled by the reversing valve, and it is easy to operate. This series of mixer can mix concretes, slurry and mortar with all kinds of mixing proportion.

Features:

     1. JD series concrete mixer is a new type of concrete mixer with multiple functions. Machines in this series can apply for the mix of plastic concrete, dry concrete, light weight aggregate concrete and different mortars.

    2.  JD series concrete mixer have the advantages of wide application range, good mixing quality, high production efficiency, low energy consumption and noise. Besides, reasonable structure, easy operation, high speed of discharging, long service life of liner and blades and easy maintenance are also the strong points of JD series concrete mixer.

   3.  JD series concrete mixers are the ideal machines for construction sites as well as small and medium component company.

Main parameters of JD series concrete mixer



model	JDC350	JDC500	JDY350	JDY500
Discharge capacity(L)	350	500	350	500
Feeding capacity(L)	560	800	560	800
Max production rate	17.5-21 m³/h	20-30 m³/h	17.5-21 m³/h	20-30 m³/h
Maximum aggregate sizes(pebble/gravel)	60mm/40mm	80mm/60mm	60mm/40mm	80mm/60mm
Mixing blade(rational speed )	25 r/min	25 r/min	25 r/min	25 r/min
Mixing motor power(kw)	15	18.5	15	18.5
Hoist motor power(kw)	4.5	5.5	4.5	5.5
Pump motor power(kw)	0.75	1.1	0.75	1.1
Discharging method	Gear-drive	Gear-drive	Hydraulic	Hydraulic
Size(mm)	4150×2600×3150	4330×2750×5000	4150×2600×3150	4330×2750×5000
Total weight(kg)	3500	3700	3500	3700
Speed of Hopper lifting(m/min)	18	18	18	18
