Hydraulic discharging double-shaft 1500 concrete mixer lift
series of the concrete mixer is twin-shaft forced type one, can mix dry hard, plastic, liquid, such as lightweight aggregate concrete and a variety of mortar. Drum set with high manganese cast steel liner and mixing blade, durable, and easy to replace. This machine is designed reasonable, compact, easy to operate, reliable, good quality with stirring, high efficiency, low energy consumption, noise and so on.
1. The machine owns the advantages of independent operation under one machine and forms a simple concrete mixing station with PLD serial batching machines.
2. It may provides matching principal machines to mixing stations, applicable for large, medium, and small-size prefabrication components plants and industrial and civil construction engineering including roads, bridges, water conservancy and docks.
1 |
Lubrication |
Automatic |
2 |
Type |
Twin-horizontal force stirrer |
3 |
Reducer |
2*30KW |
4 |
Charging/Discharging volume |
2400L/1500L |
5 |
Discharging height |
3.8M |
6 |
Discharge Way |
Auto |
7 |
Working Cycle Period |
30s |
8 |
Max. aggregate size |
80/60mm |
9 |
Mixing blade and scale board |
High chrome, resistant material |
Other models of mixer
Model |
JS2000 |
JS1500 |
JS1000 |
JS750 |
JS500 |
Output capacity |
2000L |
15000L |
1000L |
750L |
500L |
Feeding Capacity |
3200l |
2400L |
1600L |
1200L |
800L |
Mixing time |
35-45S |
35-45S |
35-45S |
35-45S |
35-45S |
Production Capacity |
>=100m3/h |
>=75m3/h |
>=50m3/h |
>=37-45m3/h |
>=20-30m3/h |
Rated motor power |
37×2KW |
30×2KW |
18.5KW×2 |
30KW |
18.5KW |
Max particle size of aggregate |
60/80mm |
60/80mm |
60/80mm |
60/80mm |
60/80mm |
Power of hoist motor |
22KW |
18.5KW |
13KW |
7.5KW |
5.5KW |
Power of water pump |
4KW |
4KW |
3KW |
1.1-1.5KW |
0.75-1.1KW |
Total weight |
15000KG |
11130KG |
9500KG |
5500KG |
3500KG |
